HN-8810A/B is a two-component addition-cure (platinum-catalysed) thermally conductive silicone potting compound with a low viscosity and a convenient 1:1 mix ratio by weight. It offers excellent thermal conductivity of 1.0 W/m·K, good fluidity and self-levelling for easy pouring, and cures at room temperature or with heat acceleration. The cured elastomer keeps its rubber elasticity across a wide service range of −40 °C to 150 °C, with strong high-temperature resistance, anti-ageing performance, excellent electrical insulation and waterproof / moisture-proof protection.
Key Features of Silicone Potting Compound
- Excellent thermal conductivity: 1.0 ± 0.1 W/m·K
- Low viscosity and good fluidity for easy pouring and self-levelling
- 1:1 mix ratio (A:B by weight); room-temperature or heat curing
- Wide operating temperature range: −40 °C to 150 °C
- Good high-temperature resistance and anti-ageing properties
- Excellent electrical insulation; volume resistivity ≥ 5.0 × 1014 Ω·cm
- Flame retardant: UL94 V-0
- Waterproof and moisture-proof; protects electronic assemblies from humidity
Typical Applications of Silicone Potting Compound
- Potting protection of general electronic components, power modules and circuit boards
- Automotive HID lamp module power supplies
- Automotive ignition system module power supplies
- Network transformers and various electronic appliances
- General electronic encapsulation requiring thermal dissipation, insulation and waterproof protection
Technical Data of Silicone Potting Compound
| Property | Unit | Value |
|---|---|---|
| Appearance (Component A / B) | — | White liquid / Grey liquid |
| Base Chemistry | — | Polysiloxane (Silicone) |
| Viscosity (A / B) | mPa·s (cP) | 2000–3000 / 2000–3000 |
| Density (A / B) | g/cm³ | 2.0 ± 0.02 |
| Mix Ratio (A:B) | by weight | 1:1 |
| Mixed Viscosity | mPa·s | 2000–3000 |
| Cure Time (Heat Accelerated) | min @ 80 °C | 10–20 |
| Volume Resistivity | Ω·cm | ≥ 5.0 × 1014 |
| Thermal Conductivity | W/m·K | 1.0 ± 0.1 |
| Flame Retardant Rating | UL94 | V-0 |
| Operating Temperature Range | °C | −40 to 150 |
Mixing & Application Instructions
- Pre-mix: Stir Components A and B thoroughly and separately before use so that settled filler is uniformly dispersed.
- Weighing: Accurately weigh A and B in a 1:1 ratio by weight using a precision scale.
- Mixing: Mix A and B thoroughly by hand or machine until the colour is uniform.
- Degassing: Place the mixed compound in a vacuum cabinet to remove entrapped air.
- Potting: Pour the degassed compound into the clean, dry device to complete potting.
- Curing: Cure at room temperature or heat cure at 80 °C for 10–20 minutes.
Packaging
- Component A: 25 kg iron / plastic drum
- Component B: 25 kg iron / plastic drum
- Kit (A+B): 50 kg / set (25 kg + 25 kg)
Storage & Shelf Life
- Store in original, tightly sealed containers in a cool, dry, well-ventilated area below 25 °C.
- Protect from direct sunlight, moisture, heat and extreme temperatures.
- Shelf life: 6 months from date of manufacture when stored unopened and properly sealed.
