High Thermal Conductivity Silicone Potting Compound 2.0 W/mK for Power Module Encapsulation
HN-8820A/B Two-Component Addition-Cure Silicone Potting Compound 2.0 W/m·K
HN-8820A/B is a two-component, addition-cure (platinum-catalysed) silicone potting compound engineered for efficient heat dissipation. With a thermal conductivity of 2.0 W/m·K, a low-viscosity 1:1 mix ratio by weight and good self-levelling fluidity, it pours easily and cures at room temperature or with heat acceleration. The cured grey elastomer (Shore A 45–50) keeps its rubber elasticity across a wide range and delivers excellent electrical insulation with reliable waterproof, moisture-proof and anti-ageing performance.
Key Features of Silicone Potting Compound
- Thermal conductivity of 2.0 ± 0.1 W/m·K for effective heat dissipation
- Wide operating temperature range: −40 °C to 200 °C
- Excellent electrical insulation: volume resistivity ≥ 5.0 × 1014 Ω·cm
- UL 94 V-0 flame retardancy
- Low viscosity (5000–8000 mPa·s) and 1:1 mix ratio for easy processing and degassing
- Good waterproof, moisture-proof and anti-ageing performance
- Cured hardness 45–50 Shore A for durable mechanical protection
Typical Applications of Silicone Potting Compound
- Potting and protection of general electronic components and circuit boards
- Power modules, including automotive HID lamp module power supplies
- Automotive ignition system module power supplies
- Network transformers and other electronic appliances
Technical Data of Silicone Potting Compound
| Property | Unit | Value |
|---|---|---|
| Appearance (Component A / B) | — | White liquid / Grey liquid |
| Base Chemistry | — | Polysiloxane (Silicone) |
| Viscosity (A / B) | mPa·s | 5000–8000 / 5000–8000 |
| Density (A / B) | g/cm³ | 2.0 ± 0.02 |
| Mix Ratio (A:B) | by weight | 1:1 |
| Mixed Viscosity | mPa·s | 5000–8000 |
| Cure Time (Heat Accelerated) | min @ 80 °C | 10–20 |
| Appearance (Cured) | — | Grey elastomer |
| Hardness | Shore A | 45–50 |
| Thermal Conductivity | W/m·K | 2.0 ± 0.1 |
| Volume Resistivity | Ω·cm | ≥ 5.0 × 1014 |
| Flame Retardancy | UL 94 | V-0 |
| Operating Temperature Range | °C | −40 to 150 |
Mixing & Application Instructions
- Pre-mix: Stir Component A thoroughly before use as fillers may settle; shake or stir Component B well.
- Weighing: Accurately weigh A and B per the 1:1 ratio by weight (not volume) using a precision scale.
- Mixing: Mix until uniform in colour; scrape container walls and bottom. Avoid introducing excessive air.
- Degassing (optional): For void-sensitive applications, degas under vacuum to remove entrapped air.
- Pouring / Potting: Pour the mixed compound into the clean, dry device within pot life, ensuring full coverage.
- Curing: Heat-accelerate at 80 °C for 10–20 minutes, or cure at room temperature (refer to pot life). Do not stress the part during cure.
Packaging
- Component A: 25 kg plastic barrel
- Component B: 25 kg plastic barrel
- Kit (A+B): 50 kg / set (25 kg + 25 kg)
Storage & Shelf Life
- Store in original, tightly sealed containers in a cool, dry, well-ventilated area at 5–25 °C.
- Protect from direct sunlight, moisture and extreme temperatures.
- Shelf life: 6 months from date of manufacture when stored as recommended.
