Used Wheel Loader LG856H Heavy Duty Wheel Loader 5500kg Stage IV Emission
【Product Overview】
The LG856H is a 5-ton heavy-duty wheel loader meticulously developed by Lonking, with a rated load capacity of 5500 kg and a standard bucket capacity of 3.6 m³. This model features reinforced front and rear frames with an extra-long 3350mm wheelbase, delivering an operating weight of 18400 kg. It provides exceptional stability and tipping load performance. Powered by the Weichai Stage IV engine, it delivers robust power while meeting higher emission standards, making it ideal for heavy-duty applications including mining, ports, and large-scale infrastructure projects.
【Key Specifications】
| Parameter | Value |
|---|---|
| General Parameters | |
| Rated Load Capacity | 5500 kg |
| Operating Weight | 18400 ± 300 kg |
| Standard Bucket Capacity | 3.6 m³ |
| Bucket Capacity Range | 3.0 - 5.0 m³ |
| Maximum Traction Force | 185 ± 5 kN |
| Maximum Breakout Force | ≥175 kN |
| Dump Height (45°) | 3350 ± 30 mm |
| Engine System | |
| Engine Model | Weichai |
| Rated Power | 170 kW @ 2200 rpm |
| Emission Standard | Stage IV |
| Drivetrain | |
| Transmission Type | Heavy-duty Planetary Power Shift Transmission with High Speed Ratio |
| Drive Axle | Reinforced Heavy-duty Drive Axle |
| Hydraulic System | |
| System Type | Dual Pump Converging System |
| Control Method | Pilot Control (Standard) |
| Brake System | |
| Parking Brake | Air-controlled with protection switch |
| Start Protection | Forced Neutral Start |
【Overall Dimensions】
| Parameter | Value |
|---|---|
| Overall Length | Approx. 8900 mm |
| Overall Width | Approx. 3100 mm |
| Overall Height | Approx. 3450 mm |
| Wheelbase | 3350 mm |
| Track Width | Approx. 2200 mm |
【Key Features】
1. Powerful and Eco-Friendly Engine
Equipped with the Weichai Stage IV engine, meeting Tier 4 emission standards. Delivers strong power output with excellent fuel economy.
2. Reinforced Structure for Superior Stability
The front and rear frames adopt a reinforced design, providing enhanced structural rigidity, torsional resistance, and durability. The 3350mm extra-long wheelbase significantly improves tipping load capacity and overall machine stability.
3. Large Capacity Bucket for High Efficiency
Standard 3.6 m³ large-capacity bucket with replaceable tooth design for easy and quick maintenance.
4. Heavy-duty Drivetrain for Durability
The heavy-duty planetary power shift transmission with high speed ratio is perfectly matched to the engine. The reinforced drive axle ensures reliable performance under demanding heavy-duty conditions.
5. Comfortable Operation with Safety Features
-
Dual pump converging hydraulic system with standard pilot control for flexible and efficient operation
-
Air-controlled parking brake with protection switch and forced neutral start for enhanced safety
-
Lonking 4th generation cab with spacious interior, comfortable ride, and modern aesthetic design
6. Intelligent Management System
Equipped with Lonking's intelligent management system, allowing users to monitor equipment operation data and status in real-time via mobile phones or computers.
【Typical Applications】
-
Mining and quarry operations
-
Port and terminal cargo handling
-
Large-scale infrastructure projects
-
Aggregate yards and concrete batching plants
-
Logistics and material transfer centers
【Optional Configurations】
-
Multiple bucket capacity options (3.0 - 5.0 m³)
-
Various attachments (forks, log grapple, side dump bucket, etc.)
-
Air conditioning system
-
Reverse camera system
|
|
|
|
|
|
|
|
