Second Hand SHANTUI SR22M-C5 22ton Road Roller Compactor Dual Frequency 40KW Engine
Price:
39,000 – 43,000 USD (Contact us for a detailed quote)
MOQ:
1 unit (customizable according to user needs )
Delivery Time:
30-45 days (in stock for conventional models, customized models need to be negotiated separately
Brand:
SHANTUI
Product Description
The SHANTUI SR22M-C5 is a 22-ton mechanical single drum vibratory roller designed for heavy-duty compaction applications. Powered by the Weichai WP6 engine delivering 140 kW of power, this model features dual-frequency and dual-amplitude vibration system for superior compaction efficiency. With its mechanical drive system, three-speed forward and reverse operation, and robust structural design, the SR22M-C5 is ideal for highway construction, airport runways, dam projects, and large-scale earthworks.
Key Specifications
| Parameter | Value |
|---|---|
| I. Basic Performance Parameters | |
| Model | SR22M-C5 |
| Product Type | Mechanical Single Drum Roller |
| Operating Weight | 22000 kg |
| Drum Diameter | 1550 mm |
| Drum Width | 2140 mm |
| Theoretical Gradeability | 35% |
| II. Compaction Performance | |
| Vibration Frequency | 29 / 35 Hz (Dual frequency) |
| Nominal Amplitude | 1.86 / 0.93 mm (Dual amplitude) |
| Centrifugal Force | 410 / 300 kN |
| Front Wheel Static Linear Load | 516 N/cm |
| III. Power and Drive System | |
| Engine Model | Weichai WP6 (China III) |
| Rated Power / Speed | 140 kW @ 1800 rpm |
| Forward Speeds (3 gears) | 2.8 / 5.6 / 9.1 km/h |
| Reverse Speeds (3 gears) | 2.8 / 5.6 / 9.1 km/h |
| Fuel Tank Capacity | 300 L |
| IV. Dimensions and Structure | |
| Overall Dimension (L×W×H) | 6517 × 2362 × 3180 mm |
| Transport Dimension (L×W×H) | 6388 × 2362 × 3180 mm |
| Wheelbase | 3200 mm (reference) |
| Minimum Ground Clearance | 440 mm |
| Minimum Turning Radius | 6500 mm |
| Steering Angle | ±33° |
Key Features
- Powerful Compaction Performance
Equipped with dual-frequency (29/35 Hz) and dual-amplitude (1.86/0.93 mm) vibration system, delivering centrifugal forces of 410 kN and 300 kN for superior compaction of various materials from soil to asphalt. - High-Performance Engine
Powered by the Weichai WP6 engine delivering 140 kW at 1800 rpm, providing ample power for demanding compaction applications with excellent fuel economy. Compliant with China III emission standards. - Mechanical Drive System
Features a mechanical drive system with three forward and three reverse speeds (2.8/5.6/9.1 km/h), offering reliable power transmission and easy operation for various job site conditions. - Three-Stage Vibration Isolation
Adopts three-stage vibration isolation design, significantly reducing vibration and noise levels for enhanced operator comfort during extended working hours. - Ergonomic Cab Design
Human-engineered cab layout with convenient controls reduces operator fatigue, improving overall productivity and safety. - Electric Shift Transmission
Equipped with electric shift transmission for smooth and effortless gear changes, enhancing operational efficiency. - Excellent Maneuverability
With a minimum turning radius of 6500 mm and ±33° steering angle, the SR22M-C5 offers outstanding maneuverability in confined spaces and challenging terrain.
Main Application Areas
- Highway and expressway construction
- Airport runway projects
- Dam and embankment construction
- Large-scale industrial sites
- Port and terminal infrastructure
- Heavy earthworks compaction
|
|
|
|
|
|
