Doosan DX215-9C 21 Ton Excavator with 115 kW Power 136.2 kN Digging Force
Price:
34,900 – 35,500 USD (Contact us for a detailed quote)
MOQ:
1 unit (customizable according to user needs )
Delivery Time:
30-45 days (in stock for conventional models, customized models need to be negotiated separately
Brand:
DOOSAN
Product Description
Product Overview
The Doosan DX215-9C is a 21-ton class hydraulic excavator powered by the DL06 engine delivering 115 kW of power. With an operating weight of 20,600 kg and a standard bucket capacity of 0.92 m³, this model combines exceptional digging performance with excellent fuel efficiency. The DX215-9C is ideal for general earthmoving, road construction, residential development, and infrastructure projects.
Key Specifications
| Parameter | Value |
|---|---|
| I. Basic Specifications | |
| Model | DX215-9C |
| Tonnage Class | 21 tons |
| Operating Weight | 20600 kg |
| Bucket Capacity | 0.92 m³ (Standard) / 0.86 m³ (Optional) |
| Boom / Stick Length | 5700 mm / 2900 mm |
| Track Shoe Width | 600 mm |
| Ground Pressure | 45.8 kPa |
| II. Engine (DL06) | |
| Engine Type | 6-cylinder in-line, Turbocharged, Water-cooled, High-pressure common rail |
| Rated Power | 115 kW @ 1900 rpm |
| Bore × Stroke | 100 × 125 mm |
| Displacement | 5.9 L |
| Fuel Type | Diesel (China III / Euro III) |
| III. Performance Parameters | |
| Bucket Digging Force | 136.2 kN |
| Stick Digging Force | 98 kN |
| Maximum Digging Radius | 9873 mm |
| Maximum Digging Depth | 6592 mm |
| Maximum Digging Height | 9616 mm |
| Maximum Dumping Height | 6830 mm |
| Travel Speed (High/Low) | 5.3 / 2.9 km/h |
| Swing Speed | 9.8 rpm |
| IV. Hydraulic System | |
| Main Pump Type | 2 × Variable displacement piston pump |
| Main Pump Flow | 2 × 191 L/min |
| Pilot Pump Flow | 32 L/min |
| Working Hydraulic Pressure | 34.3 MPa |
| Travel Hydraulic Pressure | 34.3 MPa |
| Swing Hydraulic Pressure | 26.5 MPa |
| V. Dimensions (mm) | |
| Overall Length | 9506 mm |
| Overall Width | 2800 mm |
| Overall Height (To Boom Top) | 2891 mm |
| Overall Height (To Cab Top) | 2985 mm |
| Track Gauge | 2590 mm |
| Minimum Ground Clearance | 475 mm |
| VI. Fluid Capacities | |
| Fuel Tank | 400 L |
| Hydraulic Tank | 195 L |
| Engine Oil (Including Filter) | 27 L |
| Coolant | 26 L |
| VII. Travel / Swing Components | |
| Carrier Rollers (Each Side) | 2 units |
| Track Rollers (Each Side) | 7 units |
| Track Shoes (Each Side) | 45 pieces |
| Swing Brake Type | Wet multi-disc |
| Travel Reduction Type | Planetary gear |
Key Features
- Powerful and Fuel-Efficient Engine
Equipped with the Doosan DL06 engine delivering 115 kW at 1900 rpm, featuring 6-cylinder in-line configuration with turbocharger and high-pressure common rail system. Delivers exceptional power with excellent fuel economy, compliant with China III / Euro III emission standards. - High Digging Force
Delivers 136.2 kN bucket digging force and 98 kN stick digging force, ensuring excellent penetration and loading capability in tough materials. - Excellent Working Range
With 5700 mm boom and 2900 mm stick configuration, the machine achieves maximum digging depth of 6592 mm, reach of 9873 mm, and dumping height of 6830 mm, suitable for a wide range of applications. - Advanced Hydraulic System
Features dual variable displacement piston pumps with total flow of 382 L/min (2×191 L/min). Working pressure of 34.3 MPa provides responsive and powerful implement control for fast cycle times. - Superior Travel Performance
Dual-speed travel system with high speed of 5.3 km/h and low speed of 2.9 km/h ensures excellent mobility across varying terrain conditions. - Large Fluid Capacities
400 L fuel tank extends operating hours between refueling, while 195 L hydraulic tank ensures adequate cooling capacity for extended operation. - Heavy-Duty Undercarriage
Features 7 track rollers and 2 carrier rollers per side with 45 track shoes each, providing excellent stability and durability in demanding conditions. - Reliable Braking System
Wet multi-disc swing brake and planetary gear travel reduction ensure reliable braking performance and smooth operation.
Main Application Areas
- General earthmoving and excavation
- Road construction and maintenance
- Residential development
- Utility installation
- Material handling operations
- Infrastructure projects
|
|
|
|
