SANY HBT60.13 Electric Trailer Mounted Concrete Pump 13MPa Pressure 75kW Electric Motor
Price:
17000-22000USD
MOQ:
1 unit (customizable according to user needs )
Delivery Time:
30-45 days (in stock for conventional models, customized models need to be negotiated separately
Brand:
SANY
Product Description
Product Specifications
1. Basic Information
Brand: SANY
Model: HBT60.13 Series
Type: Trailer-Mounted Concrete Pump (Electric Powered)
Condition: Used / Refurbished (Adjust as per actual condition)
Place of Origin: Hunan, China (Mainland)
2. Pumping Performance
Max. Theoretical Concrete Output (High/Low Gear): 60 m³/h / 30 m³/h
Max. Theoretical Concrete Pressure (High/Low Gear): 13 MPa / 8 MPa
Hopper Capacity: 0.6 m³
Delivery Cylinder (Bore × Stroke): Φ180 mm × 1400 mm
S-Valve Diameter: Φ180 mm
Max. Aggregate Size: 30 mm
Applicable Concrete Slump Range: 80–230 mm
Max. Vertical Delivery Distance: 120 m
Max. Horizontal Delivery Distance: 400 m
3. Power System
Power Source: Electric Motor
Rated Power: 75 kW
Voltage: 380V / 400V (Optional)
Frequency: 50Hz / 60Hz (Optional)
Control Mode: Manual + Wireless Remote Control
4. Hydraulic & Control System
Hydraulic System Type: Closed-Loop, Constant Power Control
Main Hydraulic Pump: Axial Piston Variable Pump
Max. Hydraulic System Pressure: 31.5 MPa
Hydraulic Oil Tank Capacity: 350 L
Cooling System: Air-Cooled Radiator
Lubrication System: Automatic Centralized Lubrication
5. Chassis & Structure
Trailer Type: Single Axle Trailer
Overall Dimensions (L×W×H): 6800 × 2000 × 2400 mm
Operating Weight: Approx. 6200 kg
Outrigger Type: Manual Hydraulic Outriggers
Tire Specification: 10.00R20
6. Standard Configuration
- S-Valve reversing system
- 75kW electric motor
- Automatic centralized lubrication system
- Wireless remote control
- High-pressure water washing system
- Hydraulic outriggers
- Air-cooled hydraulic radiator
![]()
![]()
![]()
![]()
