SANY HBT9028CH Diesel Trailer Mounted Concrete Pump with 2 × 180 kW rated power

SANY HBT9028CH Diesel Engine Trailer Pump:

I. Basic Information

- Model: HBT9028CH-5S (Diesel Version, S-Valve Ultra-Hh Pressure)
- Overall Weight: 11,910 kg
- Dimensions: 7508 × 2272  2750 mm (L×W×H)
- Hopper Capacity: 0.7 m³
- Loading Height: 1,420 mm

II. Pumping Performance

- Theoretical Output (Low Pressure/High Pressure): 95 / 70 m³/h
- Maximum Theoretical Pumping Pressure (Low Pressure/High Pssure): 19 / 28 MPa
- Delivery Cylinder: Φ200 × 2100 mm
- Maximum Aggregate Size: 50 m (Gravel) / 40 mm (Crushed Stone)
- Delivery Pipe Diameter: Φ150 / Φ125 mm
- Applicable Sump: 100～230 mm

III. Power System

- Engine: Dual Diesel Engines
- Rated Power: 2 × 180 kW (2200 rpm)
- buting Valve: S-Valve Switchover
- Hydraulic System: Differential Pressure Sensing Switchover, High-Flow Main Valve, Automatic Piston Reraction

IV. Core Technologies and Features

- Intelligent Control: Fault Self-Diagnosis, Dedicated Motion Controller, Forced Pumping
- Energy Saving Technology: Load Adaptive Power Control, aves about 25% Fuel
- Wear Resistance Technology: 5th Generation Wear Parts (Eye Plate/Cutting Ring/Delivery Cylinder)
- Mixing System: High Torque Motorced Feeding, High Suction Performance
