Mineral Wool Insulation Autoclave Sterilizer Machine with Piping Internal Surface Roughness Less Than 1.0um
Mineral Wool Insulation Autoclave Sterilizer Machine with Piping Internal Surface Roughness Less Than 1.0um
Technical Standard
- GB150.1~GB150.4-2011 Steel Pressure Vessel
- GB/T 191-2008 Pictorial Markings for Handling of Packages
- GB4793.1-2007 Measurement, Control and Lab Safety Requirements of Electrical Equipment, Part 1: General Requirement
- GB9969.1-1998 General Principles for Preparation of Instructions for Use of Industrial Products
- GB/T14710-2009 The Environmental Requirements and Test Methods for Medical Electrical Equipment
- GB18278-2000 Sterilization of Health Care Products--Requirements for Validation and Routine Control--Industrial Moist Heat Sterilization
- JB/T4711-2003 Coating, Shipping and Packing of Pressure Vessel
- YY0076-1992 Metal Parts Classification Technology Conditions of Coating
- YY0085.1-1992 Pulse Vacuum Pressure Steam Sterilizer
- SFDA 2010 version GMP
- Chinese Pharmacopoeia 2010
- Supervision Regulation on Safety Technology for Fixed Type Pressure Vessel
- ISPE, Volume 4, Water and Steam System, Edition 1, Jan 2001
Quality Standards
- cGMP
- ISO 9001:2008 - Quality Management Systems
- ISO 13485:2012 Quality Management System – Medical Devices
Specification
|
Model |
MDB-1.0 |
|
Door number |
Double door |
|
Door type |
Motorized Hinge Door |
|
Chamber volume |
1000 liters |
|
Chamber Size |
680*1180*1250mm |
|
Overall Size |
1160*2000*1590mm |
|
Net Weight |
1550kg |
|
Steam |
40Kg/cycle |
|
Water |
100Kg/cycle |
|
Power(KVA) |
4KVA |
|
Sterilization temperature rage |
105°C to 134°C |
|
Sterilization time rage |
0---99 minutes |
|
Vacuum times |
0---9 times |
|
Drying time |
0---99 minutes |
|
Components |
Pneumatic valves |
|
PLC, touch screen control, micro-printer recorder |
|
|
With stainless steel cart and trolley. |
Materials
|
Chamber |
STEEL |
|
|
304 L stainless steel |
STANDARD |
|
|
316 L stainless steel |
|
|
|
Jacket |
STEEL |
|
|
304 L stainless steel |
STANDARD |
|
|
316 L stainless steel |
|
|
|
Door internal side |
STEEL |
|
|
304 L stainless steel |
STANDARD |
|
|
316 L stainless steel |
|
The Medpharm Difference
1. Quality and Innovation – Dedicated to sterilizers for over 15 years.
2. Steam Sterilizers are Our Only Business – Proud to be the only major steam sterilizer
3. Manufacturer specializing in Steam Sterilizers
4. Simplicity of Design – less parts to fail
5. Vacuum, Gravity, Liquid and Test Cycles - Standard on all Sterilizers
6. Chamber Finish – Most sanitary in the industry. Providing a mirror finish of <20 Micro Inches
Ra, the result is a non-porous surface easy to clean and hostile to microorganism
7. Turn Key Operation – from planning to installation to start-up and training
Medpharm sterilizers represent state-of-the-art technology, built to the highest standards thanks to employees who have a strong work ethic and dedication to craftsmanship. Quality products and personal service is first and foremost with Medpharm.
