Automation Autoclave Sterilizer Machine With Pressure Gauge And Pressure Reducing Valve
Automation Autoclave Sterilizer Machine With Pressure Gauge And Pressure Reducing Valve
Feature
|
Feature |
Benefit |
|
Unique non-stick door gasket |
Specially formulated to eliminate sticking and to avoid door jamming,FDA food grade silicon. |
|
Air-actuated gasket |
Minimize steam exposure and extend working life. |
|
Whisper-quiet air compressor optional |
Minimize noise,eliminate need for air supply,supply constant air pressure to gasket |
|
Side-mounted control |
Avoids steam exposure to electronics and extends touchscreen life |
|
One style solenoid valve used throughout sterilizer |
Simplifies maintenance,non-proprietary valve reduces cost |
|
Integrated post-vac drying cycle |
Vacuum drying phase eliminates steam and removes moisture from the load((i.e. reduces wet-packs) |
|
Pressure gauge calibration |
Permits periodic calibration to maintain accuracy,extend component life |
|
Customizable design |
All sliding door sterilizers are custom made to exact configuration,functionality and options |
|
Automatic power door operation |
Powered door operation allows 1 finger open/close operation.The door can be manually operated in the event of power loss. |
Specification
- Continuous chamber and jacket in high quality nickel-chrome stainless steel.
- Controlled by Mitsubishi industrial microcomputer and user-friendly, high resolution, colour touch screen.
- Stainless steel valves and steam pipes.
- Steam pipes connected using a tube CLAMP system: laboratory quality offered as standard.
- Integrated steam discharge system using the silent and efficient Venturi ejector.
- Automatic electric doors with safety system.
- Water saving system (optional).
- Prepared for remote operation (online remote maintenance).
- With inlets for validation sensors.
- Access ports for PC connection and barcode reader (optional).
- Non-condensable gas-measuring module (optional).
- Variants: for sunken area- floor level loading- or on plinth- raised loading on the ground.
- Optional automatic loading/unloading.
Description
Medpharm manufactures and markets a wide range of sterilizers, accessories and equipment that have been designed to meet the sterilization needs of health centres, pharmaceutical laboratories, universities, as well as for the treatment of biohazardous waste.
Applications
Cover a large field of applications for hospitals, CSSD and medical centers. Medpharm sterilizers are also used in laboratories, in the pharmaceutical and other industries, as the additional programs enable them to sterilize medical solutions, microbiological cultures and mediums.
Competitive Advantage
- Additional temperature sensor in chamber for liquids sterilizing
- All pipes and fitting are made of stainless steel AISI 316L
- Validation IQ/OQ
- Slot for connection with external PC for data transfer on the front panel
- Bio-seal optional
