Horizontal Sliding Door 1500 Liters Stainless Steel Pass Through Sterilization Cycle Autoclave

Horizontal Sliding Door 1500 Liters Stainless Steel Pass Through Sterilization Cycle Autoclave

Application

Pass through steam sterilization offers a wide range of application and is mainly used in the harmaceutical and biotechnology industries. Main application can be sterilization of

- Porous load, stainless steel instruments, empty bottles, vials and plastic containers, filters

and stoppers.

- Solution in Glass container like ampoules, vials and bottles

- Terminal sterilization of ampoules and bottles

- Sterilization of IV, Fluids in PVC pouches

Main Parameters

Features

• Operating Temperature and pressure:
  – Sterilizing Temp. : 121°C.
  – Sterilizing Pressure : 1.2 to 1.5 kg/Cm2, (15 psi to 22 psi)
• The Chamber bottom, particle filters and strainers are easy to clean. Vacuum piping has a filter preventing bedding from being sucked in.
• PLC validation as per 21CFR part 11
• Dimple jacket of 316L provided for enhanced/uniform and temperature distribution (within±1℃) during the sterilization phase.
• Multiple validation ports
• Bioseal: A biological safety barrier separates the sterile and non-sterile zone.
• Integrated sterile section with isolator.
• Trays, carriage and floor trolleys provided.
• Pneumatically operated sliding doors with safety interlocks.
• Dedicated after sales service with well trained technicians.

Competitive Advantage

Our pass through autoclave has been engineered to meet the stringent manufacturing standards like cGMP being followed by the pharmaceutical & bio-tech industries, medpharm believes in total customer satisfaction and control in quality in production in accordance with GAMP and ISO guidelines &provide DQ,OQ,IQ enables customer standards.

Brochure load down from here

Medpharm medical large steam autoclave brochure.pdf
