Electric Heated Benchtop Autoclaves With Pressure And Temperature Controller
Electric Heated Benchtop Autoclaves With Pressure And Temperature Controller
Features
- 24 Liter autoclave chamber volume
- Chamber Pressure Gauge
- 304 Stainless Steel Chamber and Door
- Heated by Electric power
- With adjustable timer and adjustable pressure / temperature controller
- Beep alarm and shut off after cycle finish
- Door safety locking system
- Safe protection of water lack, over temperature, over pressure
- Permission-based Door Release
Description
The bench top autoclave series is an affordable sterilizer for laboratories that do not want to compromise on quality, safety and reliability and need to sterilize loads with low sensitivity. The autoclave in chamber sizes ranging from 20 to 24 liters. Process control is preformed by a pressure switch.The control system includes a timer that can be set from 1 to 60 minutes.
Specifications
|
Model |
Chamber |
Dimensions |
Loading tray |
Package Dimension |
NW/GW |
|
BT-20XAJ |
20L(φ250 *420mm) |
480*480*385mm |
340*200*30mm (3pcs) |
700*580*500mm |
38/43Kg |
|
BT-24XAJ |
24L(φ250 *520mm) |
580*480*385mm |
400*200*30mm (3pcs) |
800*580*500mm |
44/50Kg |
|
Max working pressure |
0.22MPa |
||||
|
Max working temperature |
134℃ |
||||
|
Adjustment of temperature |
105---134℃ |
||||
|
Adjustment of Timer |
0---60min |
||||
|
Chamber temperature difference |
≤±1℃ |
||||
|
Electric power |
1.5kW/AC 220V, 50/60Hz |
||||
Advantages
Medpharm benchtop autoclaves are built in the China for years of trouble-free operation, even in the most adverse conditions.
Modular design is completely upgradable to meet your evolving needs.
Each unit is designed for safe operation under all conditions, and fitted with industry Control System.
Our autoclaves offer an unparalleled 12-month parts and labor warranty.
