Autoclave Pharmaceutical Sterilizers Offer 13000 Liters Autoclave For Infusion Solution

Pharmaceutical Autoclave Sterilizers Supplier Offer 13000L Autoclave For Infusion Solution

Description

Superheated water spray autoclave manufactured by Medpharm, a pharmceutical autoclave sterilizers supplier from China are designed for cGMP to perform terminal sterilisation of large volume infusion/parenteral solution in Non-deformable container (e.g. glass bottles) as well as in containers deformable by differential pressure under Heat exposure (e.g. plastic bottles, plastic bags) proven to withstand sterilization condition by hot water spray.

Applications

Suitable for sterilization for large volume infusion/parenteral solutions in sealed glass, PP, PE, etc. bottles and PVC, PP,PE, etc. bags

Features

  ♦ High flow circulation centrifugal pumps

  ♦ Plate type heat exchanger for efficient heating and cooling of water.

  ♦ Special distribution plate arrangement for optimal water shower

  ♦ Installation is floor or pit mounted

  ♦ Optional automatic loading - unloading system

  ♦ Single or double door, automatic sliding type

  ♦ Water distribution headers & spray nozzles arranged in a manner to ensure uniform heat distribution

  ♦ Temperature & pressure monitoring inside the chamber

  ♦ PLC & HMI based control system with provision for SCADA connectivity.

  ♦ Range of alarms & safety devices for product, process & operator safety

  ♦ Strip chart or paperless recorders available

  ♦ High powered centrifugal pump used for re-circulation of water in the system

  ♦ All international brands piping and valves used to exemplify the performance of the machine (optional)

Parameter:

•  Max working pressure: 0.27MPa
•  Max working temperature: 126℃
•  Steam pressure: 0.4---0.8MPa
•  Compressed air: 0.4---0.8MPa
•  Water: 0.2---0.4MPa

Competitive Advantage

Water is a pure media for sterilization, no second population. It can recycle use in the super

heated water spray sterilizer can kill bacteria in high pressure and high temperature. It is a

critical advantages compared with other method sterilization.
