TA Type Rubber Swab Cups for 2'' 2-1/2'' 2-7/8'' 3-1/2'' Tubing
High-Efficiency Fluid Lifting Solutions for Oilfield Services
As a premier oilfield rubber parts manufacturer, we provide high-performance TA Type Rubber Swab Cups specifically engineered for medium to heavy-duty fluid recovery operations. Our swab cups are designed to offer a superior seal against the tubing wall, ensuring maximum lift and minimal fluid loss during well intervention and cleanout.
The TA Type swab cup is a reinforced, all-purpose tool featuring a high-strength steel or aluminum insert. It is the industry standard for swabbing operations where durability and consistent performance are required across various tubing sizes, including 2", 2-1/2", 2-7/8", and 3-1/2".
Key Features of Our TA Type Swab Cups
1. Reinforced Structural Integrity
Our TA Type cups feature a heavy-duty metal bushing that provides a solid foundation. This design allows the cup to maintain its shape under heavy fluid loads while ensuring the rubber expands correctly to create a positive seal during the upward stroke.
2. Abrasion-Resistant Rubber Compound
We use a proprietary blend of high-tear-strength elastomers. This ensures the rubber swab cup can withstand the friction of long-distance swabbing in rough or corroded tubing without premature wear.
3. Versatile Pressure Response
The TA profile is uniquely responsive to hydrostatic pressure. As the fluid weight increases, the cup's lips press more firmly against the tubing ID, preventing "slippage" and maximizing the volume of fluid recovered per trip.
4. Chemical & Sour Service Resilience
For wells containing high levels of H2S or aggressive frac fluids, we offer HNBR and FKM (Viton) compounds that resist swelling, hardening, and chemical degradation.
Applications & Usage
1. Fluid Recovery: Lifting water or oil to initiate or increase production flow.
2. Wellbore Cleanout: Removing completion fluids, silt, or debris from the tubing string.
3. Swabbing Operations: Essential for workover rigs and service companies performing routine maintenance.
4. Testing & Evaluation: Used to recover fluid samples from specific depths within the well.
Size Selection Guide
Choosing the correct size is vital for operational efficiency. Our TA Type cups are precision-molded for:
2" Tubing: For slim-hole completions and small-diameter pipes.
2-1/2" Tubing: Common for standard oil and gas production strings.
2-7/8" Tubing: The industry-preferred size for high-volume swabbing.
3-1/2" Tubing: Designed for heavy-duty, large-bore tubing applications.
Why Choose Us as Your Swab Cup Supplier
1. Factory Direct Pricing: Eliminate middleman costs by sourcing directly from the manufacturer.
2. Custom Formulations: We can adjust rubber durometer (hardness) and material based on your specific well depth and temperature.
3. Quality Assurance: Each batch undergoes rigorous pressure and tensile testing to meet international oilfield standards.
4. Global Export Capability: Fast shipping to North America, the Middle East, and Southeast Asia.
Frequently Asked Questions (FAQ)
Q: Are your TA Type cups compatible with my existing mandrels?
A: Yes. Our TA Type cups are designed to be universally compatible with all industry-standard swabbing mandrels and tool strings.
Q: Which material should I choose for high-temperature wells?
A: For temperatures exceeding 250°F (121°C), we recommend our HNBR or FKM (Viton) compounds, which maintain elasticity and sealing properties up to 400°F.
Q: Can you provide private labeling (OEM)?
A: As a manufacturer, we offer full OEM services, including custom branding and packaging for large-scale distributors and service companies.
Technical Specifications & Parameters
| Parameter |
Detailed Specification |
| Available Sizes |
2", 2-1/2", 2-7/8", 3-1/2" (Full Range Available) |
| Bushing Materials |
High-Grade Steel / Lightweight Aluminum |
| Elastomer Options |
Nitrile (NBR), HNBR, Fluorocarbon (FKM) |
| Working Pressure |
Up to 10,000 PSI (Dynamic pressure dependent) |
| Operating Temperature |
Standard (NBR): -20°F to 250°F (-29°C to 121°C) <br> High-Temp (HNBR/FKM): Up to 400°F (204°C) |
| Compatibility |
Standard Swabbing Mandrels and Tool Strings |
| Application Environment |
Crude Oil, Water, H2S (Sour Service), CO2, Brine |
Our Company & Factory
Established in 2013 within the Shanghai Free Trade Zone, Qinuo is a high-tech enterprise specializing in rubber seal manufacturing for the Oil & Gas sector. We integrate R&D, production, and sales under our core philosophy: "Quality for Survival, Innovation for Development." This commitment has earned us recognition across global markets, where we currently promote our Royal Way and SHQN brands in the energy industry.
Qinuo provides professional design and production services for rubber parts, plastic components, and machined parts. Our solutions serve diverse sectors including oil & gas, automotive, home appliances, and industrial equipment. Guided by our principles of "High Quality, High Professionalism, High Efficiency," our dedicated team ensures excellence at every stage.
We operate two wholly-owned factories in Nantong City—strategically located just one hour from Shanghai Pudong Airport and Shanghai Port. Equipped with over 30 rubber vulcanization presses and supporting machinery, we produce more than 20 types of rubber seals and related products. Our monthly production capacity exceeds 20 tons (approximately 40,000 lbs), and we continue to expand rapidly.
Operating under a comprehensive ISO9001-based quality management system, we export to over 100 countries including the USA, Canada, UK, Germany, Finland, and Australia. We're confident in our ability to meet your requirements and look forward to a productive partnership.
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
