Auatralia Shutter Door Biting Machine Auxiliary Equipment
Auatralia Shutter Door Biting Machine Auxiliary Equipment Of Roll Form Machine
Roll shutter door roll forming machine is customized by YBT Machinery company. We design and produce many kinds of roll shutter door roll forming machine for many clients. We understand shutter door very well. And we also know the shutter door roll forming machine market very well. When we get the sample of shutter door panel, we can get price timely.
Business should be honest, then we can help you to buy high quality shutter door roll forming machine with acceptable price.
Details of Shutter Door Roll Forming Machine
| Suitable raw material | PPGI/PPGL/GI/GL Steel Coils |
| Thickness of coil sheet | 0.3-0.8mm |
| Feeding Coil width | 156mm |
| Effective width | 115mm |
| Under frame | 600H-beam |
| Diameter of Soild shaft |
50mm, high grade 45# steel, finish turning, cylindrical grinding, with keyway |
| Roller |
High grade 45# steel, processed by CNC lathe, Quenched and tempered treatment,hard chrome coated 0.05-0.07mm |
| Thickness of middle plate | Memorical archway |
| Forming stations | 12 |
| Drive type | By chain(1.0 inch) link bearing model 6210 |
| Power of main motor | 5.5kw with Cycloidal reducer, Lichao, Shanghai |
| Power of pump station | 4kw, Lichao, Shanghai |
| Forming speed | About 15-20m/min |
| Hydraulic cutting | Controlled by PLC |
| PLC | DELTA, TAIWAN / Mitsubishi, Japan |
| Material of cutting blade | Cr12Mov, quenching 58-62°C |
| Frequency converter |
It has the advantage of slowing down before cutting, to ensure the length accuracy(±1mm, far better than industrialstandard ±3mm). |
Machine Detailed Parameters:
| 1 | Machine structure | Wire-electrode cutting structure |
| 2 | Total power | Motor power-7.5kw Hydraulic power-4kw |
| 3 | Roller stations | About 14 stations + one station for rectify (according the final design) |
| 4 | Productivity | 0-15m/min |
| 5 | Drive system | By 1.2 inch single chain |
| 6 | Diameter of shaft | ¢65mm solid shaft |
| 7 | Voltage | 380V 50Hz 3phases (Customized) |
| 8 | Container need | 1x20GP container |
Auatralia Shutter Door Biting Machine ,Design according to customers requirement
