N95 Automatic Mask Forming Maker Making Machine With Breath Valve Making Machine
N95 Automatic Mask Forming Maker Making Machine With Breath Valve Making Machine
| Technical Parameters of N95 Mask Machine | ||||
| SN | 1 | 2 | 3 |
4 |
| Product Name | N95 cup-shaped mask forming machine | N95 Mask Forming Machine | N95 Cup-type mask welding punching machine | N95 cup mask punching machine: |
| Dimensions | 1085*1100*1610mm | 1800*560*630mm | 535*1015*1055mm | 480*350*540mm |
| Weight | 420kg | 200kg | 530kg | 91kg |
| Power | 3.6KW | 2KW | 4.2KW | 0.76KW |
| Capacity | 30-36 pcs/min | 50-100 pcs/min | 10-15 pcs/min | 10-15 pcs/min |
| SN | 5 | 6 | 7 | 8 |
| Product Name | N95 Cup Mask Breathing Valve Welding Machine: | N95 cup mask pad printer | N95 cup-shaped mask bridge welding machine | N95 cup-shaped mask ear band applicator |
| Dimensions | 460*520*1000mm | 620*360*1185mm | 480*800*760mm | 535*1015*1055mm |
| Weight | 90 | 120 | 60 | 75 |
| Power | 1.5KW | 1.2KW | 0.8KW | 0.6KW |
| Capacity | 6-10 pcs/min | 10-15 pcs/min | 15-20 pcs/min | |
N95 Mask Machine Whole Set 8 Parts:
1.N95 cup-shaped mask forming machine: The cup-shaped mask forming machine uses the high-temperature hot-pressing principle to produce the shaped part of the cup-shaped mask.
2.N95 Mask Forming Machine: The cup-shaped mask mask forming machine is also known as the mask mask slicer. This machine uses the principles of ultrasonic cutting and automatic welding and edge sealing. It scans the cup-shaped mask structure to make a special mold to complete the mask jacket cutting and welding.
3.N95 Cup-type mask welding punching machine: PLC control, human-machine interface touch screen display, fully displaying the humanized operation concept; using ultrasonic welding, with a special knife die cutting device, welding punching is completed at one time, the blanking is exquisite and firm without hurting the material; The edge is not loose; the two heads of welding and cutting work at the same time, and the six stations automatically turn the table, the movement is accurate and no deviation.
4.N95 cup mask punching machine: mechanical punching, high production efficiency, smooth and smooth surface of mask cutting, high accuracy; easy operation; it is a domestic manufacturer of N95 mask complete equipment;
5.N95 Cup Mask Breathing Valve Welding Machine: Welding using the ultrasonic principle, the welding effect is strong without affecting the appearance, the traditional riveting is solved, the mold can be changed at will, and the operation is convenient.
6.N95 cup mask pad printer: microcomputer control with high degree of automation and easy operation; printing stroke and speed can be adjusted; automatic balance scraper to ensure balanced printing pressure; the use of imported shaft center and shaft sleeve makes the silk screen scraper smoothly slide printing; operation Speed can be adjusted independently.
7.N95 cup-shaped mask nose welding bar welding machine: The pneumatically pushed principle is used to push the glued aluminum bar. After heating, the surface glue is melted and combined with the gas to promote the bonding on the periphery of the nose bridge. Completed in one pass without harming the surface of the N95 mask.
8.N95 cup-shaped mask ear band laminating machine: spot welding of mask ear bands, high production efficiency and easy operation; using infrared fixed point, movable mold.
