Cold Roll Forming Machine / Steel Roof Batten Rock Wool Production Line
Thickness 0.4-1.2mm Cold Roll Steel Roof Batten Roll Forming Machine
YBT Machinery Equipment Co.,Ltd is professional manufacture of roll forming machine. We can provide design and instruct clients to do projects, offer technical support for clients, including project design, drawing supplied and engineer supplied.The advantages of roof batten roll forming machine are as follows: Easy operation, low maintenance cost,Topspan style model is available.
1 . Components for the Machine:
| Main motor power | 5.5 kw. |
| Hydraulic station power | 5.5kw. |
| Feeding width | 1250mm. |
| Cover width | 1092mm |
| Yield stress | 235Mpa (33KSI) ~ 345Mpa (50KSI). |
| Roll forming Speed | 15-18 m/min 3-4 m/minute (including step pressing and cutting) |
| Cutting Tolerance | +/-2.5mm(length≤5000mm); +/-3.0mm(5000mm<length≤10000mm). |
| Manual Uncoiler | Max. Capacity: 5000kgs. |
| Coil inner diameter | 508mm. |
| Voltage | 380V,3 Phase,50HZ,Or As per customer's request. |
| Numbers of stands | 10 stations |
| Type of cutting | Roll-formed and length-set profile cutting. |
2 . Technical parameters
Cut-to-lengthtolerance≤±2 mm
Control Voltage 24V
User's manualin English
| Suitable for material with thickness | 0.4-1.2mm |
| Motor driving | Gear chain transmission, 14 rollers to form |
| Main motor | 5.5KW/7.5KW , Frequency speed control. Forming speed approx.18m/min |
| PLC Control System | Touch screenbrand:German Schneider Electric/Taiwan WEINVIEW, |
3 . Process of Rolling form machine
Uncoiling →Infeed guiding →Roll forming →Pressing→Measure Length&Shearing →Sheet to Support Table
Roof batten roll forming machine post cutter
Brand Original: China
No need to change cutter for different size,
made by high quality mold steel Cr12 with heat treatment
Cutter frame made from high quality 20mm steel plate by welding
hydraulic motor:5.5KW, Hydraulic pressure range: 0-12Mpa
Manual Decoiler: one set
Un-powered,manually control steel coil inner bore shrinkage and stop
Max. feeding width: 500mm, coil ID range 470mm±30mm
Capacity: Max. 3Ton
4 . After-sale service of roof batten roll forming machine
1 . The warranty of roof batten roll forming machineis one year after the client receives the machine.
Within the one year, we will courier the replacement parts to the client free of charge.
2 . We offer technical support for the entire life of our machines.We can send our technicians to install and train the workers in the clients' factories with extra cost.
3. Terms of trade of ceiling batten machine : a. Minimum order quantity (MOQ): 1 piece b.Delivery time: about 45 workdays c.Port of loading: port of Shanghai
