Fireproof Sheet Roller Shutter Door Making Machine , Door Panel Roll Forming Machine Custom Color
PLC Control fireproof sheet roller shutter door roll forming machine equipment
Description:
The machine works stably and no noise. In addition, it's easy to control and operate. Our machines are welcomed by global customers for high precision, especially in Russia, middle east and China. We can customize machines according to customer's requirements and offer free after-sale service. This product is very popuar and widely used in family structure, building structure, shopping mall, office etc.
Echnical parameters
| Name | metal steel fireproof roller shutter door frame cold making production line/Slide shutter door machine |
| Suitable to process | Color steel plate, galvanized sheet, aluminum coils and etc. |
| Width of the feeding material | 100-160mm |
| Roller station | 10-15 rows |
| Thickness of feeding material | 0.3-1.2mm |
| Power Supply | 380V, 3-Phase,50Hz |
| Productivity | 10-20m/min |
| Rollers' material | 45# steel |
| Diameter of shaft | 75mm |
| Roller Diameter | 50mm |
| Wall thickness of main forming machine | 14mm steel plate |
| Main forming machine body | 300 mm H steel |
| Motor power | 4+3kw |
| Cutter Standard | GCr12 |
| Size | 7500*1500*1600mm |
| Weight | About 2.5T |
| Custom |
According to customer's requirements
|
Machine components:
| 1 | Decoiler | 1 set |
| 2 | Guide Feeding device | 1 set |
| 3 | main forming machine | 1 set |
| 4 | Foaming machine (just foamed one owned) | 1 set |
| 5 | Straighten device | 1 set |
| 6 | Punching device | 1 set |
| 7 | flying saw cutting machine | 1 set |
| 8 | finished products table | 1 set |
| 9 | PLC control system PLC | 1 set |
| 10 | Spare Parts And Tools | 1 set |
Packaging & Shipping
1. Main body of Shutter Door Frame Roll Forming Machine is naked and covered by plastic film(to protect of dust and corrosion),loaded into container and steadily fixed in 1x40GP container with steel rope and lock catch suitable for long-distance transportation,
2. spare parts are covered by plastic film.
3. With even lifting point in the machine for easy container loading and uploading.
Warranty:
1 year warranty, we also will supply technical and fittings after warranty
After-services:
if you come to our factory examine goods, we will teach you how to control machine until completed control it
