China 12v 24v 25mm Dc Electric Gear Motor Low Rpm 1rpm 5rpm 1w 2w 5kgcm for sale

12v 24v 25mm Dc Electric Gear Motor Low Rpm 1rpm 5rpm 1w 2w 5kgcm

Name: 12v 24v 25mm Dc Electric Gear Motor Low Rpm 1rpm 5rpm 1w 2w 5kgcm
Brand: Wenzhou Tyhe Motor Co., Ltd.

Price Negotiable

Price: Negotiation

MOQ: 500pcs

Delivery Time: 15 working days after payment

Brand: TYHE

Product Description

Products Description

Commodity Stocks 12v 24v 25mm Low Rpm 1rpm 5rpm 1watt 2w 5kgcm Torque Dc Electric Gear Motor In India

2D drawing

Model	End cover dimensions	Motor type	Regular Shaft	Weight
TJZ25RB	φ25mm	RF310	4mm-D cut	80g

Specifications

DC Motor Technical Data
Model	Rated Voltage(V)	No-Load Parameters		Rated Parameters					Stall Parameters
		Speed	Current	Speed	Current	Torque	Output	eff	Torque	Current
		rpm	mA	rpm	A	mN.m	W	%	mN.m	A
310	6	3000	10	2400	0.03	0.46	0.12	62.49	1.38	0.19
310	6	5000	26	4000	0.08	0.72	0.30	62.31	2.16	0.50
310	6	6000	31	4800	0.11	0.79	0.40	62.14	2.37	0.72
310	6	6800	45	5440	0.13	0.84	0.48	61.74	2.52	0.74
DC Motor With Gearbox Technical Data (0.3M)
Gearbox parameters			6V-3000RPM Input				6V-5000RPM Input
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
19	81	4.8	500.0	0.09	1.79	5.37	833.3	0.24	2.80	8.40
19	81	5.7	421.1	0.09	2.12	6.37	701.8	0.24	3.32	9.97
19	73	10.6	226.4	0.08	3.56	10.68	377.4	0.22	5.57	16.71
19	73	12.5	192.0	0.08	4.20	12.59	320.0	0.22	6.57	19.71
19	73	14.7	163.3	0.08	4.94	14.81	272.1	0.22	7.73	23.18
19	65.6	23.0	104.3	0.08	6.94	20.82	173.9	0.20	10.86	32.59
19	65.6	27.5	87.3	0.08	8.30	24.90	145.5	0.20	12.99	38.97
19	65.6	32.0	75.0	0.08	9.66	28.97	125.0	0.20	15.11	45.34
19	65.6	38.0	63.2	0.08	11.47	34.40	105.3	0.20	17.95	53.84
22	59	51.5	46.6	0.07	13.98	41.93	77.7	0.18	21.88	65.63
22	59	60.5	39.7	0.07	16.42	49.26	66.1	0.18	25.70	77.10
22	59	71.0	33.8	0.07	19.27	57.81	56.3	0.18	30.16	90.48
22	59	83.0	28.9	0.07	22.53	67.58	48.2	0.18	35.26	105.78
22	59	98.0	24.5	0.07	26.60	79.79	40.8	0.18	41.63	124.89
24	53	113.0	21.2	0.06	27.55	82.65	35.4	0.16	43.12	129.36
24	53	133.0	18.0	0.06	32.43	97.28	30.1	0.16	50.75	152.26
24	53	156.0	15.4	0.06	38.03	114.10	25.6	0.16	59.53	178.59
24	53	184.0	13.0	0.06	44.86	134.58	21.7	0.16	70.21	210.64
24	53	215.0	11.2	0.06	52.42	157.25	18.6	0.16	82.04	246.13
24	53	253.0	9.5	0.06	61.68	185.04	15.8	0.16	96.54	289.63
27	47.8	249.0	9.6	0.06	54.75	164.25	16.1	0.14	85.70	257.09
27	47.8	293.0	8.2	0.06	64.42	193.27	13.7	0.14	100.84	302.52
27	47.8	344.0	7.0	0.06	75.64	226.92	11.6	0.14	118.39	355.17
27	47.8	404.0	5.9	0.06	88.83	266.49	9.9	0.14	139.04	417.12
27	47.8	474.0	5.1	0.06	104.22	312.67	8.4	0.14	163.13	489.40
27	47.8	557.0	4.3	0.06	122.47	367.42	7.2	0.14	191.70	575.09
27	47.8	654.0	3.7	0.06	143.80	431.40	6.1	0.14	225.08	675.24
DC Motor With Gearbox Technical Data (0.3M)
Gearbox parameters			6V-6000RPM Input				6V-6800RPM Input
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
19	81	4.8	1000.0	0.32	3.07	9.21	1133.3	0.39	3.27	9.80
19	81	5.7	842.1	0.32	3.65	10.94	954.4	0.39	3.88	11.63
19	73	10.6	452.8	0.29	6.11	18.34	513.2	0.35	6.50	19.50
19	73	12.5	384.0	0.29	7.21	21.63	435.2	0.35	7.67	23.00
19	73	14.7	326.5	0.29	8.48	25.43	370.1	0.35	9.01	27.04
19	65.6	23.0	208.7	0.26	11.92	35.76	236.5	0.31	12.67	38.02
19	65.6	27.5	174.5	0.26	14.25	42.75	197.8	0.31	15.15	45.46
19	65.6	32.0	150.0	0.26	16.58	49.75	170.0	0.31	17.63	52.90
19	65.6	38.0	126.3	0.26	19.69	59.08	143.2	0.31	20.94	62.82
22	59	51.5	93.2	0.23	24.00	72.01	105.6	0.28	25.52	76.57
22	59	60.5	79.3	0.23	28.20	84.60	89.9	0.28	29.98	89.95
22	59	71.0	67.6	0.23	33.09	99.28	76.6	0.28	35.19	105.56
22	59	83.0	57.8	0.23	38.69	116.06	65.5	0.28	41.13	123.40
22	59	98.0	49.0	0.23	45.68	137.03	55.5	0.28	48.57	145.71
24	53	113.0	42.5	0.21	47.31	141.94	48.1	0.25	50.31	150.92
24	53	133.0	36.1	0.21	55.69	167.06	40.9	0.25	59.21	177.63
24	53	156.0	30.8	0.21	65.32	195.95	34.9	0.25	69.45	208.35
24	53	184.0	26.1	0.21	77.04	231.12	29.6	0.25	81.92	245.75
24	53	215.0	22.3	0.21	90.02	270.06	25.3	0.25	95.72	287.15
24	53	253.0	19.0	0.21	105.93	317.79	21.5	0.25	112.64	337.91
27	47.8	249.0	19.3	0.19	94.03	282.08	21.8	0.23	99.98	299.94
27	47.8	293.0	16.4	0.19	110.64	331.93	18.6	0.23	117.65	352.94
27	47.8	344.0	14.0	0.19	129.90	389.70	15.8	0.23	138.12	414.37
27	47.8	404.0	11.9	0.19	152.56	457.68	13.5	0.23	162.21	486.64
27	47.8	474.0	10.1	0.19	178.99	536.98	11.5	0.23	190.32	570.96
27	47.8	557.0	8.6	0.19	210.33	631.00	9.8	0.23	223.65	670.94
27	47.8	654.0	7.3	0.19	246.96	740.89	8.3	0.23	262.59	787.78
