12V 24V 37v10 Watt Brushless Dc Spur Gear Motor For Smart Home 37mm 600 Rpm
Price:
Negotiation
MOQ:
120pcs
Delivery Time:
15 working days after payment
Brand:
TYHE
Product Description
Products Description
Manufacturer 12 v 24 Volt 12v 37v 37mm 600 Rpm 4kgf 10 watt Brushless Dc Spur Gear Motor for Smart Home
2D drawing
Specifications
| DC Motor Technical Data | ||||||||||
| Model | Rated Voltage(V) | No-Load Parameters | Rated Parameters | Stall Parameters | ||||||
| Speed | Current | Speed | Current | Torque | Output | eff | Torque | Current | ||
| rpm | mA | rpm | A | mN.m | W | % | mN.m | A | ||
| 3650BL | 12 | 5000 | 350 | 4000 | 1.07 | 19.20 | 8.04 | 62.83 | 57.60 | 6.50 |
| 3650BL | 24 | 5000 | 158 | 4000 | 0.54 | 19.80 | 8.29 | 63.85 | 59.40 | 3.65 |
| DC Motor With Gearbox Technical Data (0.5M) | ||||||||||
| Gearbox parameters | 12V-5000RPM Input | 24V-5000RPM Input | ||||||||
| Length (mm) | Transmission Efficiency (%) | Gear Ratio | Rated Output Speed (RPM) | Rated Output Power (W) | Rated Torque (mN.m) | Maximum Instantaneous Torque (mN.m) | Rated Output Speed (RPM) | Rated Output Power (W) | Rated Torque (mN.m) | Maximum Instantaneous Torque (mN.m) |
| 25.5 | 81 | 8.2 | 487.8 | 6.51 | 127.53 | 382.58 | 487.8 | 6.72 | 131.51 | 394.53 |
| 25.5 | 73 | 11.7 | 341.9 | 5.87 | 163.99 | 491.96 | 341.9 | 6.05 | 169.11 | 507.34 |
| 25.5 | 73 | 14.7 | 272.1 | 5.87 | 206.04 | 618.11 | 272.1 | 6.05 | 212.47 | 637.42 |
| 25.5 | 73 | 19.1 | 209.4 | 5.87 | 267.71 | 803.12 | 209.4 | 6.05 | 276.07 | 828.21 |
| 27.5 | 65.6 | 27.2 | 147.1 | 5.28 | 342.59 | 1027.77 | 147.1 | 5.44 | 353.30 | 1059.89 |
| 27.5 | 65.6 | 34.4 | 116.3 | 5.28 | 433.27 | 1299.82 | 116.3 | 5.44 | 446.81 | 1340.44 |
| 27.5 | 65.6 | 44.5 | 89.9 | 5.28 | 560.49 | 1681.46 | 89.9 | 5.44 | 578.00 | 1734.00 |
| 29.5 | 59 | 63.5 | 63.0 | 4.74 | 719.33 | 2157.98 | 63.0 | 4.89 | 741.81 | 2225.42 |
| 29.5 | 59 | 80.3 | 49.8 | 4.74 | 909.64 | 2500.00 | 49.8 | 4.89 | 938.06 | 2500.00 |
| 29.5 | 59 | 104.0 | 38.5 | 4.74 | 1178.11 | 2500.00 | 38.5 | 4.89 | 1214.93 | 2500.00 |
| 32.5 | 53 | 148.0 | 27.0 | 4.26 | 1506.05 | 2500.00 | 27.0 | 4.40 | 1553.11 | 2500.00 |
| 32.5 | 53 | 187.0 | 21.4 | 4.26 | 1902.91 | 2500.00 | 21.4 | 4.40 | 1962.38 | 2500.00 |
| 32.5 | 53 | 242.0 | 16.5 | 4.26 | 2462.59 | 2500.00 | 16.5 | 4.40 | 2500.00 | 2500.00 |
| 35.5 | 47.8 | 346.0 | 11.6 | 3.84 | 2500.00 | 2500.00 | 11.6 | 3.96 | 2500.00 | 2500.00 |
| 35.5 | 47.8 | 437.0 | 9.2 | 3.84 | 2500.00 | 2500.00 | 9.2 | 3.96 | 2500.00 | 2500.00 |
| 35.5 | 47.8 | 565.0 | 7.1 | 3.84 | 2500.00 | 2500.00 | 7.1 | 3.96 | 2500.00 | 2500.00 |
Please let us know your requirements and we will provide you with transmission solutions.
