150LB CF8M Gate Valve Wafer Type Rising Stem Stainless Steel

                                                 150LB CF8M Rising Stem Wafer Type Knife Gate Valve

Features:
Designed for easy, quick conversion between manual and pneumatic actuation. Featuring a lubricant injection port for continuous, smooth operation with minimal maintenance.
Clevis design and horizontal bolting stabilizes gate ensuring proper alignment.
Standard multi-layer square packing provides exceptional gland sealing.
Optional energized quad seal packing for enhanced gland sealing.
Wiper/Anti Extrusion Ring minimizes the gap between the body and the gate
Unrestricted flow path with minimal pressure drop achieved through full port valve design
Deflection resistant gate design ensures consistent alignment for industry leading durability
Replaceable flexible wire reinforced elastomer seat ensures bidirectional zero leakage shutoff

Specifications:

Bidirectional Knife Gate Valve

Size Range: 2 – 36" (50 – 900mm)
Body Materials: CF8 Stainless Steel, CF8M Stainless Steel, CF3M Stainless Steel, SAF 2205, SAF 2507, WCB Carbon Steel
Pressure Ratings:
2 – 24" (50 – 600mm) 150psi (10 bar),
30 – 36" (750 – 900mm) 100psi (7bar)
Stem Materials: 304 Stainless Steel
Body Style: Single Piece, Lug
Gate Materials: 304, 316, 317, SAF 2507, SAF 2205,17-4PH, Hastelloy® C, Monel®


Temperature:

Seat Material Temperature Range:
Buna-N: -34 to 194°F (-36 to 90°C),
EPDM: -65 to 248°F (-54 to 120°C)
Viton®: -15 to 392°F (-26 to 200°C)

Packing Maximum Temperature:
PTFE: 500°F (260°C),
Impregnated PTFE: 450°F (232°C),
PTFE/Buna-N: 194°F (90°C),
PTFE/Viton®: 392°F (200°C),
PTFE/EPDM: 248°F (120°C)

Standards:

Testing Standard: MSS SP-151
Certifications: CE/PED, Canadian CRN, AWWA C520 (2019)
Face to Face: MSS SP-81

Actuator Options: Handwheel, Bevel Gear, Pneumatic, Hydraulic, Electric

Applications: Bleach Stock, Brown Stock Washers Pump Isolation, Evaporators Black Liquor, Paper Stock, Fly Ash Pneumatic Conveyance Crossover Valve, RAS Return Activated Sludge, Pump & Equipment Isolation, Process Fluids, Pump & Isolation Tank

Features & Benefits:

The Lug bidirectional knife gate valve provides repeatable bidirectional shutoff in a rugged, single piece cast body. Featuring a replaceable steel-reinforced elastomer seat for enhanced sealing, tgate valve is easily automated for on/off applications.
