WCB Non Rising Stem Gate Valve 300LB ANSI B16.5 With Bonnet

                                                        300LB WCB Non-Rising Stem Knife Gate Valve with Bonnet

Bonnet Knife Gate Valves are a unidirectional valves designed for isolation application where Solid‐Liquid mixes, corrosive, abrasive, viscous liquid, abrasive slurries, pulp stock and dry materials are involved. The Bonnet is cast or fabricated depending on valve size and pressure rating of the valve. Sealing to atmosphere is achieved using a round gland sealing arrangement on top of the bonnet. This assures very tight sealing which is not normally feasible on standard knife gate valves with a large rectangular packing area. Bonnet valves are generally used for buried services where
backfill covers the valve and also suitable for application requiring a high level of gland tightness such as dangerous and toxic gases. The
bonnet also prevents internal corrosion from fluid handled. Flush ports also provided to clean the bonnet periodically.Purging can be made with air, steam, liquids, etc. depending on the fluid handled.

Product Feature:

- Size : 6” to 52”
- End Style : Full Lugged or ANSI Flange
- Working Pressure : 2” to 24” ‐ 150 Psi (10 bar)
- Standard flange connection : ANSI B16.5 (class 150) and others on request
- Seat : Metal / Resilient
- Design conforms to : MSS SP‐81

Application:
- Pulp and Paper
- Power plants
- Mining
- Chemical plants
- Wastewater
- Food and Beverage etc.
