Wire Diameter 3mm 3.8mm 4mm Dust Collector Filter Cage Corrosion Resistant
Wire Diameter Φ3, 3.2, 3.5, 3.8, 4mm Corrosion-Resistant Circular Dust Collector Filter Cage With Venturi
The function of filter bag cage:
The Dust Collector Filter Cage is a cage made of carbon steel or stainless steel wires with a diameter of 3-4 pieces, and is welded vertically and horizontally by longitudinal ribs and support rings. The dust filter bag skeleton is installed on the pattern hole in the pulse dust collector and the air box type pulse dust collector to support the dust filter bag to prevent collapse, which is helpful for dust cleaning and provides dust removal efficiency. Dust is attached to the outer surface of the filter bag. When the dust-containing gas passes through the dust collector, the dust is trapped on the outer surface of the filter bag, and the clean gas enters the filter bag through the filter material and is discharged by the fan.
Galvanized treatment dust collector filter bag cage Filter bag cage production:
Strong, wear-resistant and corrosion-resistant coating
Avoid the corrosion of the skeleton surface and the adhesion of the filter bag after the dust collector runs for a period of time, which will damage the bag.
To ensure smooth bag replacement, while reducing damage to the bag during the replacement process.
Increase usage time and reduce downtime.
| Goods Name | Standard | Description | Goods Name | Standard | Description |
| Clamps | φ180 | Spring curb | 120*2 | Normal quenching steel belt | |
| φ230 | 130*2 | ||||
| φ250 | 150*2 | ||||
| φ260 | 200*2 | ||||
| φ292 | 292*2 | ||||
| φ300 | 300*2 | ||||
| Hoop | φ160 | φ300-φ270 using wire rod ofφ4.2 | 120*2.5 | ||
| φ170 | 130*2.5 | ||||
| φ180 | 150*2.5 | ||||
| φ200 | 182*2.5 | ||||
| φ210 | 202*1.3 | Quenching stainless steel belt | |||
| φ250 | φ180 using wire rod of φ3.3 | 127*1.5 | |||
| φ260 | 127*1.9 | If it is highly corrosive, we can use titanium curb | |||
| φ280 | 130*2.5 | ||||
| φ292 | φ260-φ180 using wire rod of φ3.8 | 150*2.5 | |||
| φ300 | 129.6*2.5 | ||||
| φ400 | 280*2 | ||||
| φ615 | Pendant chain device | Hung huang, pendant chain | |||
| Cap | 180 | upper cap lower cap | |||
| 200 | |||||
| 230 | Venturi tube | Carbon steel | |||
| 250 | Aluminum | ||||
| 292 | Stainless steel | ||||
| 300 | Unifying covering cap and venturi tube(integration) | ||||
| Filter cage | Material: hard-drawn wire | Galvanization treatment | Normal | Yellow | |
| White zinc plated treatment | High quality | Light silver | |||
| Organic silicon treatment | Black | ||||
| Material: stainless steel | 201-316L | ||||
| Any special requirement and production can be processed according to buyer’s sample(with | |||||
Why choose us?
1. Factory Experience: We are an experienced manufacturer with complete production lines and professional production equipment.
2. Quality assurance: We always strictly implement the quality management system, run through every detail of production, and be responsible for the products required by customers.
3. One-stop purchasing: We provide one-stop purchasing of filtration products to meet the different needs of global customers.
4. Other advantages: We respond quickly within 12 hours, provide efficient and high-quality services and competitive prices.
Filter Bag Cage Production Process:
Our factory:
Our Certificate:
More details, pls feel free to contact us, Thanks
