Three Proof Polyester Filter Bag For Coal Mill In Cement Plant
Hydrolysis-Resistant Three-Proof Polyester Filter Bag For Coal Mill In Cement Plant
Polyester Filter Bag Introduction:
Polyester filter bag is resistant to hydrolysis, acid and alkali, and has the characteristics of good air permeability, less fiber release, low density and high mechanical strength. We use the special line for normal temperature cloth bags to seal the line to prevent disconnection. Our production and inspection equipment is well-equipped, the processing technology is mature, the product quality is qualified, and the variety is diverse. According to the requirements of different working conditions, dust bags with different thickness and strength can be customized. Polyester filter bags are widely used in mining, limestone powder, cement raw materials, iron and steel industry (ironmaking, continuous casting, sintering, electric furnace dust removal), non-ferrous metal forming, calcination, purification, wood dust removal and other fields.
Polyester Filter Bag Advantage:
Low cost and widely available filter media.
Polyester Filter Bag Disdvantage:
Must oversize bag for shrinkage that can occur in temperatures above 450 Degrees F.
Polyester Filter Bag Specifications
| Artical Name | Polyester Filter Felt | Polyester Filter Felt (Oil and water repellent) |
Polyester Filter Felt (oil and water repellent anti-static) |
|
| Material | Fiber | 100%Polyester | 100%Polyester | 100%Polyester |
| Scrim | Polyester | Polyester | Polyester Anti-static Sicrim | |
| Weight | g/m³ | 550 | 550 | 550 |
| Thickness | mm | 1.9±0.1 | 1.9±0.1 | 1.9±0.1 |
| Air Permeability | m³/㎡.min.200pa | 12-18 | 12-18 | 12-18 |
| Breaking Strength(N/5cm) | Warp | ≥1000 | ≥1000 | ≥900 |
| Weft | ≥1250 | ≥1200 | ≥1200 | |
| Elongation@50N(%) | Warp | ≤35 | ≤25 | ≤35 |
| Weft | ≤55 | ≤50 | ≤55 | |
| Service Temperature(℃) |
Continuous℃ | ≤130 | ≤130 | ≤130 |
| Instant℃ | 150 | 150 | 150 | |
| Finishing | Heat setting Singeing Calendaring |
Oil and water repellent | Singeing,Calendaring, Oil and water repellent |
|
Polyester Filter Bag Applicant:
Wood industry, cement, iron, steel, metal
Production Process:
There are 19 working produres. Every product from Sinft had undergone detailed perfection.
Scientific surface treatment like heat setting, dipping, singeing, calendering and coating can signigicantly prevent the
fabric from shrinking,remove surface batting, imrove filtration effectiveness and increase heat resistant.
Package:
The dust filter bags are packed in PP woven bags or according to your requirements.
Company Introduction:
Hebei Sinft filter Co.,Ltd is a high-tech enterprise group integrating R&D, production and sales of dust
collector filter bags and filter cages. We are founded in 2007 and located in Shijiazhuang.
We own the most advanced complete sets of production equipment, the high-speed acupuncture production
lines, heat-setting and high temperature after-treatmentunits, laminating units, sewing equipment, and hanging
production lines.
Daily production capacity of filter bag is more than 7000 pcs, the scale of production and equipment are at the
forefront of the industry.
Sinft Team:
We often attend international and domestic exhibitions. The company will organize team building
activities regularly. We are not only colleagues, but also family members.
Sinft Certificate:
We have ISO 9001 Certifications. Our products are used in many places at home and abroad, such as
power plants in North America, cement plants in Europe which all Won high praise.
More details, pls feel free to contact us, Thanks
| Does not perform well with moist heat |
