Wood Industry Low Temperature Polyester Filter Bag Hydrolysis Resistant
Polyester Filter Bag Is Resistant To Hydrolysis, Acid And Alkali, And Has The Characteristics Of Good Air Permeability
Polyester Filter Bag Introduction:
Low-temperature polyester filter bags are suitable for use in baghouse dust collectors such as raw material mills, cement mills, warehouse tops and bottoms, etc., and under high humidity conditions, the surface needs to be treated with oil-repellent and waterproof treatment agent. (2) Normal and high temperature type, suitable for high temperature waste gas treatment bag filter such as cement shaft kiln, rotary kiln tail, cooler, dryer, etc. The surface is treated with oil repellent and waterproof treatment agent;
Polyester Filter Bag Advantage:
Low cost and widely available filter media.
Polyester Filter Bag Disdvantage:
Must oversize bag for shrinkage that can occur in temperatures above 450 Degrees F.
Filter production:High temperature heat setting, PTFE impregnation treatment, thermal dimensional stability, PTFE fibers are all wrapped with PTFE emulsion; PTFE membrane with low resistance, high efficiency and high filtration accuracy meets customers' ultra-low emission requirements;
Production of filter bagsThe elastic expansion ring, the stitching of the bag mouth is dislocated, and the bag mouth and the flower board are closely attached to avoid dust leakage;
Polyester Filter Bag Specifications
| Artical Name | Polyester Filter Felt | Polyester Filter Felt (Oil and water repellent) |
Polyester Filter Felt (oil and water repellent anti-static) |
|
| Material | Fiber | 100%Polyester | 100%Polyester | 100%Polyester |
| Scrim | Polyester | Polyester | Polyester Anti-static Sicrim | |
| Weight | g/m³ | 550 | 550 | 550 |
| Thickness | mm | 1.9±0.1 | 1.9±0.1 | 1.9±0.1 |
| Air Permeability | m³/㎡.min.200pa | 12-18 | 12-18 | 12-18 |
| Breaking Strength(N/5cm) | Warp | ≥1000 | ≥1000 | ≥900 |
| Weft | ≥1250 | ≥1200 | ≥1200 | |
| Elongation@50N(%) | Warp | ≤35 | ≤25 | ≤35 |
| Weft | ≤55 | ≤50 | ≤55 | |
| Service Temperature(℃) |
Continuous℃ | ≤130 | ≤130 | ≤130 |
| Instant℃ | 150 | 150 | 150 | |
| Finishing | Heat setting Singeing Calendaring |
Oil and water repellent | Singeing,Calendaring, Oil and water repellent |
|
Polyester Filter Bag Applicant:
Wood industry, cement, iron, steel, metal
Production Process:
There are 19 working produres. Every product from Sinft had undergone detailed perfection.
Scientific surface treatment like heat setting, dipping, singeing, calendering and coating can signigicantly prevent the
fabric from shrinking,remove surface batting, imrove filtration effectiveness and increase heat resistant.
Package:
The dust filter bags are packed in PP woven bags or according to your requirements.
Company Introduction:
Hebei Sinft filter Co.,Ltd is a high-tech enterprise group integrating R&D, production and sales of dust
collector filter bags and filter cages. We are founded in 2007 and located in Shijiazhuang.
We own the most advanced complete sets of production equipment, the high-speed acupuncture production
lines, heat-setting and high temperature after-treatmentunits, laminating units, sewing equipment, and hanging
production lines.
Daily production capacity of filter bag is more than 7000 pcs, the scale of production and equipment are at the
forefront of the industry.
Sinft Team:
We often attend international and domestic exhibitions. The company will organize team building
activities regularly. We are not only colleagues, but also family members.
Sinft Certificate:
We have ISO 9001 Certifications. Our products are used in many places at home and abroad, such as
power plants in North America, cement plants in Europe which all Won high praise.
More details, pls feel free to contact us, Thanks
| Does not perform well with moist heat |
