Stainless Steel Industrial Filter Cages Dust Removal High Temp Resistance
The stainless steel dust removal filter cage is the "rib" of the filter bag. It should be light and easy to install and maintain. The quality of the dust removal frame directly affects the filtering state and service life of the filter bag. The dust-removing frame manufacturing equipment introduced by our company uses a high-frequency welding machine to weld the frame into shape at one time. It has advanced processing and production technology, which can ensure the quality and performance of the dust-removing frame. The dust removal skeleton is processed by iron wire or stainless steel wire with sufficient strength and rigidity. In production, stainless steel wire with high strength and rigidity is selected for production and processing, which has high toughness and firmness.
The production types of Dust Collector Filter Cage are:
The contact surface between the stainless steel dust filter cage and the filter bag should be smooth and straight, without welding slips and burrs, so as to prevent the dust filter bag from being scratched during use. Dust adheres to the outer surface of the filter bag. When the dusty gas passes through the dust collector, the dust is trapped on the outer surface of the filter bag, while the clean gas enters the filter bag through the filter material and is discharged by the fan.
Specifications
| Types: | Round Style/Flat Style/Envelope Style/ Special Style | ||
| Number Of Wires: | 8/10/12/16/20/24 vertical wires(usually) | ||
| Ring Space: | Ring spacing standard is 6 inch or 8 inch.(15.24cm or 20.32cm) | ||
| Cage Diameter: | Cage diameters range from 4 inch to 8 inch (100mm to 200mm) | ||
| Wire thickness: | Wire thickness ranges are 2mm to 5mm | ||
| Material: | Carbon Stee, Galvanized Steel, Stainless Steel | ||
| Finishment: | Epoxy, PVC vinyl coating | ||
| Packaging: | Cages are packed in custom designed cartons | ||
| Usage: | Dust from factory of mine, wood,Cement, chemical, medicine, dying,Paint, plastic, food & other industry,such as coal fired power stations, Steel Power station, Cement industry, Paper industry & other Industrial Segments. | ||
| Advantages: | 1.no corrosion 2.no damage 3.3-5 times longer life than other bag Cage with steel | ||
| 4. economical maintenance(almost no Maintenance required) | |||
| 5.prominent effect in removing dust from Filter by pulsing 6.easy to install | |||
| 7.no ventury installation required | |||
Standard Technical Data
| Round Style | Diameter(mm) | Bag Diameter(mm) | Length(mm) |
| 115 | 120 | 2000,2400 2800, | |
| 3200,3600,4000, | |||
| 125 | 130 | 4400,4800,5200, | |
| 147 | 152 | 560,060,007,000 | |
| 195 | 200 | ||
| Flat Style | Perimeter | Bag Perimeter | Length(mm) |
| 800 | 800 | 2000 3000 4000 | |
| 5000 6000 | |||
| 900 | 900 | ||
| Envelope Style | Length Width Thickness | Bag Length Width Thickness | |
| 1500X750x25mm | 1500X750x25mm | ||
Why choose us?
1. Factory Experience: We are an experienced manufacturer with complete production lines and professional production equipment.
2. Quality assurance: We always strictly implement the quality management system, run through every detail of production, and be responsible for the products required by customers.
3. One-stop purchasing: We provide one-stop purchasing of filtration products to meet the different needs of global customers.
4. Other advantages: We respond quickly within 12 hours, provide efficient and high-quality services and competitive prices.
Filter Bag Cage Production Process:
Our factory:
Our Certificate:
More details, pls feel free to contact us, Thanks
