Non Burr Stainless Steel Filter Cage For Power Plant No Corrosion
The frame of the dust filter bag is light and easy to assemble and maintain by the user. The quality of the dust frame depends on the filtering condition and service life of the filter bag. The frame of the dust collector is a cylinder made of metal mesh, and the openings on both sides of the cylinder are connected to the air duct. . The dust filter bag frame uses the airflow pressure caused by the fan to discharge the dusty air into the surface of the dust filter bag frame, and most of the lint and dross are retained on the surface of the dust cage.
The production types of Dust Collector Filter Cage are:
The circular dedusting framework has a high production capacity, and is good at making various trapezoidal dedusting frameworks, flat dedusting frameworks and other special-shaped dedusting frameworks, and can also be designed and manufactured according to user requirements. And every frame manufactured can meet the requirements of lightness, smoothness and straightness. The annual production capacity is 2 million pieces, which can meet the urgent supply needs of customers. The company can produce and process different types and shapes of dust removal skeletons, produce and process according to customer requirements, ensure customer satisfaction, provide good services and products, and help users achieve different dust removal effects.
The stainless steel dust filter cage is light and easy to assemble and maintain by the user. The quality of the dust frame is related to the filtration status and service life of the filter bag. The frame of the dust collector is a cylinder made of metal mesh, and the openings on both sides of the cylinder are connected to the air duct. . The dust filter bag frame uses the airflow pressure caused by the fan to discharge the dusty air into the surface of the dust filter bag frame, and most of the lint and dross are retained on the surface of the dust cage.
Specifications
| Types: | Round Style/Flat Style/Envelope Style/ Special Style | ||
| Number Of Wires: | 8/10/12/16/20/24 vertical wires(usually) | ||
| Ring Space: | Ring spacing standard is 6 inch or 8 inch.(15.24cm or 20.32cm) | ||
| Cage Diameter: | Cage diameters range from 4 inch to 8 inch (100mm to 200mm) | ||
| Wire thickness: | Wire thickness ranges are 2mm to 5mm | ||
| Material: | Carbon Stee, Galvanized Steel, Stainless Steel | ||
| Finishment: | Epoxy, PVC vinyl coating | ||
| Packaging: | Cages are packed in custom designed cartons | ||
| Usage: | Dust from factory of mine, wood,Cement, chemical, medicine, dying,Paint, plastic, food & other industry,such as coal fired power stations, Steel Power station, Cement industry, Paper industry & other Industrial Segments. | ||
| Advantages: | 1.no corrosion 2.no damage 3.3-5 times longer life than other bag Cage with steel | ||
| 4. economical maintenance(almost no Maintenance required) | |||
| 5.prominent effect in removing dust from Filter by pulsing 6.easy to install | |||
| 7.no ventury installation required | |||
Standard Technical Data
| Round Style | Diameter(mm) | Bag Diameter(mm) | Length(mm) |
| 115 | 120 | 2000,2400 2800, | |
| 3200,3600,4000, | |||
| 125 | 130 | 4400,4800,5200, | |
| 147 | 152 | 560,060,007,000 | |
| 195 | 200 | ||
| Flat Style | Perimeter | Bag Perimeter | Length(mm) |
| 800 | 800 | 2000 3000 4000 | |
| 5000 6000 | |||
| 900 | 900 | ||
| Envelope Style | Length Width Thickness | Bag Length Width Thickness | |
| 1500X750x25mm | 1500X750x25mm | ||
Why choose us?
1. Factory Experience: We are an experienced manufacturer with complete production lines and professional production equipment.
2. Quality assurance: We always strictly implement the quality management system, run through every detail of production, and be responsible for the products required by customers.
3. One-stop purchasing: We provide one-stop purchasing of filtration products to meet the different needs of global customers.
4. Other advantages: We respond quickly within 12 hours, provide efficient and high-quality services and competitive prices.
Filter Bag Cage Production Process:
Our factory:
Our Certificate:
More details, pls feel free to contact us, Thanks
