No Burrs Filter Bag Cages Used In Power Generation Chemical Industry
The dust removal frame, also known as the dust removal bag cage, is an indispensable accessory for the bag filter. It is used as a frame to support the dust removal filter bag. It can be compatible with six, eight, ten, twelve, sixteen, eighteen, two Ten, twenty-four ribs, the effect of the dust removal skeleton is very large, and it is widely used in industrial places such as the dust removal industry and the chemical industry.
The production types of Dust Collector Filter Cage are:
Shape:
(External filter type) (Oval, Rhombus)
envelope type
Multi-section frame (elliptical multi-section frame. Round bag multi-section frame (insert type, chuck type))
Finished frames (frames with venturi tubes. Plastic bags, frames packed in iron frames. Neatly arranged diamond-shaped frames)
Specification
Round, elliptical, flat, envelope, trapezoidal, star, spring, and other types of dust removal skeletons can be customized according to customer requirements.
Raw materials: high-quality low-carbon steel wire, galvanized steel wire, stainless steel wire, etc.
Surface treatment: galvanized, sprayed, anti-corrosion treatment, surface silicone spraying, etc. The surface silicone coating is especially suitable for the dust collector application of large generator sets.
Specifications
| Types: | Round Style/Flat Style/Envelope Style/ Special Style | ||
| Number Of Wires: | 8/10/12/16/20/24 vertical wires(usually) | ||
| Ring Space: | Ring spacing standard is 6 inch or 8 inch.(15.24cm or 20.32cm) | ||
| Cage Diameter: | Cage diameters range from 4 inch to 8 inch (100mm to 200mm) | ||
| Wire thickness: | Wire thickness ranges are 2mm to 5mm | ||
| Material: | Carbon Stee, Galvanized Steel, Stainless Steel | ||
| Finishment: | Epoxy, PVC vinyl coating | ||
| Packaging: | Cages are packed in custom designed cartons | ||
| Usage: | Dust from factory of mine, wood,Cement, chemical, medicine, dying,Paint, plastic, food & other industry,such as coal fired power stations, Steel Power station, Cement industry, Paper industry & other Industrial Segments. | ||
| Advantages: | 1.no corrosion 2.no damage 3.3-5 times longer life than other bag Cage with steel | ||
| 4. economical maintenance(almost no Maintenance required) | |||
| 5.prominent effect in removing dust from Filter by pulsing 6.easy to install | |||
| 7.no ventury installation required | |||
Standard Technical Data
| Round Style | Diameter(mm) | Bag Diameter(mm) | Length(mm) |
| 115 | 120 | 2000,2400 2800, | |
| 3200,3600,4000, | |||
| 125 | 130 | 4400,4800,5200, | |
| 147 | 152 | 560,060,007,000 | |
| 195 | 200 | ||
| Flat Style | Perimeter | Bag Perimeter | Length(mm) |
| 800 | 800 | 2000 3000 4000 | |
| 5000 6000 | |||
| 900 | 900 | ||
| Envelope Style | Length Width Thickness | Bag Length Width Thickness | |
| 1500X750x25mm | 1500X750x25mm | ||
Why choose us?
1. Factory Experience: We are an experienced manufacturer with complete production lines and professional production equipment.
2. Quality assurance: We always strictly implement the quality management system, run through every detail of production, and be responsible for the products required by customers.
3. One-stop purchasing: We provide one-stop purchasing of filtration products to meet the different needs of global customers.
4. Other advantages: We respond quickly within 12 hours, provide efficient and high-quality services and competitive prices.
Filter Bag Cage Production Process:
Our factory:
Our Certificate:
More details, pls feel free to contact us, Thanks
