High Corrosion Resistance Dust Collector Replacement Filter Bags 1.8-2.0mm Thick
High Corrosion Resistance P84 Filter Bag For Cement Plant Kiln Head
P84 Filter Bag Introduction:
P84 filter bag is flame retardant, high temperature-resistant. Under the condition of 240 °C, the mechanical properties of P84 polyimide fiber filter material will not change, and the highest temperature resistance can reach 260 °C. The P84 polyimide fiber is not a hygroscopic fiber filter (about 3% water absorption at 65% relative humidity). In addition, P84 fiber is often implanted on the surface of the filter material to improve the filtration performance of the filter material.
Needle felt polyimide( P84) fiter bag eficiency of low back
wash pressure and high elasticity mud cake release Needle polyimide(p84) filter fabric must stored in dry well ventilated place, and should not be
long-term exposure in the sunlight.
P84 Filter Bag Advantage:
Excellent stability in applications with high dry heat temperatures, mineral acids and alkaline.
P84 Filter Bag Disdvantage:
Must oversize bag for shrinkage that can occur in temperatures above 450 Degrees F.
P84 Filter Bag Specifications:
| Name | P84/M-Fiberglass Filter Felt |
P84 Filter Felt | |
| Material | Fiber | P84/M-Fiberglass | P84 fiber |
| Scrim | Glass fiber | PTFE | |
| Weight | g/m³ | 850±20 | 550 |
| Thickness | mm | 3.1±0.2 | 2.0±0.2 |
| Air Permeability | m³/㎡.min.200pa | 20-35 | 14-18 |
| Breaking Strength(N/5cm) | Warp | ≥2500 | ≥850 |
| Weft | ≥2800 | ≥1000 | |
| Elongation@50N(%) | Warp | ≤10 | ≤25 |
| Weft | ≤10 | ≤50 | |
| Service Temperature(℃) |
Continuous℃ | ≤260 | ≤240 |
| Instant℃ | 280 | 260 | |
| Finishing | Heat setting PTFE Coating |
Singeing,Calendaring | |
P84 Filter Bag Applicant:
Waste-to-Energy, Coal Fired Boilers,Incinerators
Production Process:
There are 19 working produres. Every product from Sinft had undergone detailed perfection.
Scientific surface treatment like heat setting, dipping, singeing, calendering and coating can signigicantly prevent the
fabric from shrinking,remove surface batting, imrove filtration effectiveness and increase heat resistant.
Package:
The dust filter bags are packed in PP woven bags or according to your requirements.
Company Introduction:
Hebei Sinft filter Co.,Ltd is a high-tech enterprise group integrating R&D, production and sales of dust
collector filter bags and filter cages. We are founded in 2007 and located in Shijiazhuang.
We own the most advanced complete sets of production equipment, the high-speed acupuncture production
lines, heat-setting and high temperature after-treatmentunits, laminating units, sewing equipment, and hanging
production lines.
Daily production capacity of filter bag is more than 7000 pcs, the scale of production and equipment are at the
forefront of the industry.
Sinft Team:
We often attend international and domestic exhibitions. The company will organize team building
activities regularly. We are not only colleagues, but also family members.
Sinft Certificate:
We have ISO 9001 Certifications. Our products are used in many places at home and abroad, such as
power plants in North America, cement plants in Europe which all Won high praise.
More details, pls feel free to contact us, Thanks
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
