Durable 100% PTFE Filter Bag 6000mm Water Repellent Wear Resistance
6000 mm Water Repellent 100% PTFE Filter Bag With PTFE Membrane
PTFE Filter Bag Introduction:
PTFE filter bag is made by a three-dimensional and has a very strong high temperature resistance, wear resistance, corrosion resistance, chemical stability and good hydrolyzed resistance. It is easy to clean dust with its smooth surface, continuous working temperature 240°C, peak 260°C.
PTFE membrane bags is that they clean easier, thanks to their slick surface, this means less bag posting which suggests less wear and tear on the bags as well as the diaphragms and solenoid valves. It also means the system uses less compressed air, resulting and reduced energy costs.
PTFE Filter Bag Advantage:
1. Excellent temperature resistance: up to 260℃ (572℉)
2. Extremely long working life. Service life can reach 6 years at the temperature 66℃～240℃ and normal working conditions.
3. Excellent performance of anti-acid and anti-alkali resistance
4. Excellent filter efficiency
5. Good performances of hydrolysis stability and flame retardant
6. Suitable using on various power plant boiler and waste incineration boiler. The weakness is poor folding property and higher price.
PTFE Filter Bag Specifications:
| Name | PTFE Filter Felt | PPS/PTFE Filter Felt |
|
| Material | Fiber | PTFE fiber | PPS/PTFE fiber |
| Scrim | PTFE | PTFE | |
| Weight | g/m³ | 750 | 580±20 |
| Thickness | mm | 1.0±1.3 | 1.8±0.2 |
| Air Permeability | m³/㎡.min.200pa | 3-9 | 10-18 |
| Breaking Strength(N/5cm) | Warp | ≥760 | ≥1000 |
| Weft | ≥760 | ≥1200 | |
| Elongation@50N(%) | Warp | ≤10 | ≤30 |
| Weft | ≤45 | ≤45 | |
| Service Temperature(℃) |
Continuous℃ | ≤260 | ≤190 |
| Instant℃ | 280 | 210 | |
| Finishing | Heat setting PTFE Membrane |
Singeing,Calendaring PTFE Coating |
|
PTFE Filter Bag Applicant:
Steel Foundries,Coal Fired Power Plants, drying kilns, garbage incinerators, thermal power plants, cement.
Production Process:
There are 19 working produres. Every product from Sinft had undergone detailed perfection.
Scientific surface treatment like heat setting, dipping, singeing, calendering and coating can signigicantly prevent the
fabric from shrinking,remove surface batting, imrove filtration effectiveness and increase heat resistant.
Package:
The dust filter bags are packed in PP woven bags or according to your requirements.
Company Introduction:
Hebei Sinft filter Co.,Ltd is a high-tech enterprise group integrating R&D, production and sales of dust
collector filter bags and filter cages. We are founded in 2007 and located in Shijiazhuang.
We own the most advanced complete sets of production equipment, the high-speed acupuncture production
lines, heat-setting and high temperature after-treatmentunits, laminating units, sewing equipment, and hanging
production lines.
Daily production capacity of filter bag is more than 7000 pcs, the scale of production and equipment are at the
forefront of the industry.
Sinft Team:
We often attend international and domestic exhibitions. The company will organize team building
activities regularly. We are not only colleagues, but also family members.
Sinft Certificate:
We have ISO 9001 Certifications. Our products are used in many places at home and abroad, such as
power plants in North America, cement plants in Europe which all Won high praise.
More details, pls feel free to contact us, Thanks
