Power Stations Dust Removal Filter Bag Cage
Coke Oven Flue Gas Dust Removal Black Oval Filter Bag Cage With Galvanized Treatment
The 7 major characteristics of the dust collector frame:
1. The dust collector frame adopts galvanized technology, and the coating is stable, which avoids the surface rust and the filter bag bonding after the dust collector works for a period of time, and the bag is changed smoothly. damage.
2. The design structure is strong and the service life is longer.
3. The skeleton of the dust collector adopts a circular structure. The longitudinal ribs and anti-support rings of the bag cage are evenly distributed, and have sufficient strength and rigidity to prevent damage and deformation. Protect the mouth of the filter bag during blowing.
4. The skeleton material of the dust collector is made of 20# carbon steel, which is formed at one time by the skeleton production line, with straightness and distortion, smooth and burr-free after butt welding, and has sufficient strength to prevent de-soldering, de-soldering, virtual welding and missing welding. Phenomenon.
5. Oval, star-shaped and stainless steel cages can be provided. 6, the use of equipment to produce a molding, performance.
7. With the detachable assembly technology, the replacement parts are less and the more convenient."
Galvanized treatment dust collector filter bag cage Filter bag cage production:
The filter bag cage is the reinforcing rib of the filter bag, which should be light and easy to install and maintain. The quality of the cage is directly related to the filter state and service life of the filter bag. Every cage we make meets the requirements for tightness, flatness and stiffness.
Dust collector Filter bag filter cage Galvanized filter cage
The filter cage is the reinforcing rib of the filter bag and should be easy to install and maintain. The quality of the filter bag cage directly determines the working efficiency and service life of the filter bag. Galvanized steel filter bag cages are popular for their high hardness, light weight and smoothness. For surface treatments, we can offer spraying, silicon coating and galvanizing, all of which increase their hardness and keep them away from corrosion. And the filter cage with venturi can provide better protection for the filter bag.
Features of SS/Mild Steel Cage
1. Strong heat resistance.
2. Better protection of filter bag and connection with dust collector.
3. High dust removal efficiency.
Applications:
Power Stations,Filtered dust,Flue ash, discharging flue ash
Coal dust,Building and Construction,Cement, furnace dust, gypsum, limestone, finely ground quartz,Calcium hydroxide, lead monoxide, quicklime, acid crystals,Pure clay, phosphates, magnesite concentrate, finely ground fluorid, production of aluminum,Chemical Industry,Thomas meal (Fertilizer),Rubber compounds, sinter dust, catalysts,Sodium sulfate,Soap powder
| Specifications | |||
| Types: | Round Style/Flat Style/Envelope Style/ Special Style | ||
| Number Of Wires: | 8/10/12/16/20/24 vertical wires(usually) | ||
| Ring Space: | Ring spacing standard is 6 inch or 8 inch.(15.24cm or 20.32cm) | ||
| Cage Diameter: | Cage diameters range from 4 inch to 8 inch (100mm to 200mm) | ||
| Wire thickness: | Wire thickness ranges are 2mm to 5mm | ||
| Material: | Carbon Stee, Galvanized Steel, Stainless Steel | ||
| Finishment: | Epoxy, PVC vinyl coating | ||
| Packaging: | Cages are packed in custom designed cartons | ||
| Usage: | Dust from factory of mine, wood,Cement, chemical, medicine, dying,Paint, plastic, food & other industry,such as coal fired power stations, Steel Power station, Cement industry, Paper industry & other Industrial Segments. | ||
| Advantages: | 1.no corrosion 2.no damage 3.3-5 times longer life than other bag Cage with steel | ||
| 4. economical maintenance(almost no Maintenance required) | |||
| 5.prominent effect in removing dust from Filter by pulsing 6.easy to install | |||
| 7.no ventury installation required | |||
| Standard Technical Data | |||
| Round Style | Diameter(mm) | Bag Diameter(mm) | Length(mm) |
| 115 | 120 | 2000,2400 2800, | |
| 3200,3600,4000, | |||
| 125 | 130 | 4400,4800,5200, | |
| 147 | 152 | 560,060,007,000 | |
| 195 | 200 | ||
| Flat Style | Perimeter | Bag Perimeter | Length(mm) |
| 800 | 800 | 2000 3000 4000 | |
| 5000 6000 | |||
| 900 | 900 | ||
| Envelope Style | Length Width Thickness | Bag Length Width Thickness | |
| 1500X750x25mm | 1500X750x25mm | ||
