Real-time Fault Alert Smart IoT Dimming Photocontrol LTE-Cat.1 External SIM Card
Price:
negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
LongJoin
Product Description
Real-time Fault Alert Smart IoT Dimming Photocontrol LTE-Cat.1 External SIM Card
JL-245CG Smart IoT Dimming Photocontrol LTE-Cat.1, External SIM Card
Product Dimensions
Product Features
- ANSI C136.41 Twist-lock
- 0~10V Dimming
- Surge protection level: 6KV/3KA differential mode
- Sandwich cover for Long Life
- Multi-Volts Application
- IP67 Ready
- IR-filtered Phototransistor
Technical Specifications
| Model No. | JL-245CG |
|---|---|
| Rated Voltage | 120~277VAC |
| Applicable Voltage Range | 105~305VAC |
| Rated Frequency | 50/60Hz |
| Dimming Output | 0~10VDC |
| Wireless Communication (up) | LTE-Cat1 |
| Wireless Communication (down) | LTE-Cat1 |
| Spectral Acquisition Range | 350~1100nm; Peak wavelength 590nm |
| Rated Loading | 1000W Tungsten, 1000VA Ballast, 8A@120VAC/5A@208-277VAC e-Ballast |
| Operate Levels | Turn-On＜100Lx, Turn-Off＞150Lx / per client request |
| Power Consumption | 1.2W static, 2.4W dynamic |
| Ambient Temperature | -40℃~70℃ |
| Related Humidity | 96% |
| Fail Mode | Fail-On |
| Shell material | PC |
| Surge protection level | 6KV/3KA differential mode |
| IP level | Default IP66 |
| Factory Settings | Remote control+Adaptive mode |
| Certifications |  |
| Criterion | IEC61000-4-5; IEC61000-4-2; IEC61000-4-3; IEC61000-4-6; GB/T 17743-2017; IEC61000-4-4; IEC61000-4-11; IEC61000-3-2; GB/T2423.10-2008; UL94-V0; |
Frequently Asked Questions
Q1: What is a Real-time Fault Alert Smart IoT Dimming Photocontrol with LTE-Cat.1 and External SIM Card?
A: It is an intelligent IoT dimming photocontrol that supports LTE-Cat.1 cellular communication via an external SIM card, enabling real-time fault detection and alerting for smart lighting management.
Q2: What is the function of real-time fault alert in this smart photocontrol?
A: The real-time fault alert function monitors lamp status continuously, detects abnormalities such as lamp failure, short circuit, or abnormal voltage, and immediately sends alarm notifications to the management platform.
Q3: What are the benefits of using LTE-Cat.1 and external SIM card in this IoT photocontrol?
A: LTE-Cat.1 provides stable, low-power cellular connectivity, while the external SIM card offers flexible network configuration, making deployment easy even in areas without wired network.
Q4: How does the smart dimming function work on this IoT photocontrol?
A: It automatically adjusts brightness according to ambient light, time schedule, or remote commands, achieving precise dimming control to save energy and optimize lighting effects.
Q5: In what scenarios is this LTE-connected smart photocontrol most applicable?
A: It is widely used in smart street lighting, urban road lighting, residential area lighting, and large-scale public lighting systems that require remote monitoring, dimming and fault management.
