LTE Cat.1 0-10V DALI Adaptive Roads Parks Campuses Shopping Malls Real-time Fault Alert
JL-265CC is a NEMA single light controller developed based on 4G (LTE Cat.1) communication mode, which can be controlled remotely, configured and monitored in real time. The protection level reaches IP66. Suitable for roads, parks, campuses, shopping malls, supermarkets, factories, parks and other lighting scenes.
- Features both 0-10V and DALI 2.0 dimming outputs, automatically recognizes and adapts to drivers with different dimming methods
- 85~305VAC power supply
- 9A load capacity
- Zero crossing switch with >60,000 switching life
- 6KV/3KA surge protection
- Under-voltage/over-voltage/over-current fault self-test reporting and protection
- CLASS2.0 metering accuracy (Voltage/current/power/power factor/cumulative energy consumption)
- Built-in light sensor
- Double shell design for higher structural reliability
- External pluggable SIM card
- IP66 protection rating
| Model No. | JL-265CC |
|---|---|
| Power Supply | Rated: 100~277VAC; 50/60Hz Limited: 85~305VAC; 47/63Hz |
| Dimming Output | 0-10V and DALI 2.0 |
| Wireless Communication | 4G (LTE Cat.1) Bands: LTE-FDD: B1/B3/B5/B8 LTE-TDD: B34/B38/B39/B40/B41 |
| Load | ≤9A |
| Power Consumption | 1.2W static, 2.4W dynamic |
| Ambient Temperature | -35~85℃ |
| Operating Humidity | 5%RH~99%RH |
| Surge Protection Level | 6KV/3KA differential mode |
| IP Level | IP66 |
| Standards Compliance | IEC61000-4-5; IEC61000-4-2; IEC61000-4-3; IEC61000-4-6; GB/T 17743-2017; IEC61000-4-4; IEC61000-4-11; IEC61000-3-2; GB/T2423.10-2008; UL94-V0 |
It is an intelligent lighting control module supporting LTE Cat.1 communication, compatible with both 0-10V and DALI dimming protocols, used in roads, parks, campuses and shopping malls with real-time fault alert.
It means the device can automatically adapt to both 0-10V analog dimming and DALI digital dimming lighting fixtures, making it highly compatible with different types of LED drivers and luminaires.
LTE Cat.1 provides stable wide-area cellular connectivity, low latency, suitable cost and wide coverage, supporting reliable remote control and data transmission for large-scale lighting systems.
It monitors lamp status in real time, detects faults such as lamp failure, short circuit, dimming abnormality or communication error, and immediately sends alarm information to the cloud management platform.
It is widely used in road lighting, park lighting, campus lighting, shopping mall lighting and other large-scale public and commercial intelligent lighting projects.
