Direct Wire In Thermal Photocontrol Sub Miniature Ultra Small Buckle Type Adjustable Lux Threshold
The JL-101A photocontrol is designed to automatically control passage and doorway lighting based on ambient lighting levels. This product complies with the Standard for Non-industrial Photocontrol for Lighting Control UL773A.
- Time Delay: 20~120 seconds
- Ambient Temperature Range: -20℃ to +70℃
- PET enclosure (UL94 V-0 rated)
- Copper alloy lock nut
| Model No. | JL-101A |
|---|---|
| Rated Voltage | 120VAC |
| Rated Frequency | 50/60Hz |
| Rated Loading | 600W Tungsten, 480VA Ballast, 2A e-Ballast |
| Power Consumption | 1.5W Max. |
| Operate Levels | 10~20Lx Turn-On / 30~60Lx Turn-Off |
| Ambient Temperature | -20℃ ~ +70℃ |
| Related Humidity | 96% |
| Fail Mode | Fail-On |
| Lead Wire | AWG#18, AWM1332 |
| Rainproof Cap | Optional |
| Certifications |  |
It is an extremely compact, ultra-small buckle-style thermal photocontrol for direct wire-in installation, featuring adjustable lux threshold for precise lighting control.
The ultra-small size and buckle structure allow easy installation in limited spaces, ensure firm mounting, and fit compact lighting fixtures without taking extra room.
It allows users to set the exact ambient light level for automatic on/off switching, making the photocontrol adaptable to different installation environments.
Yes, it uses direct wire-in wiring for stable and reliable connection, suitable for small lighting equipment and narrow installation spaces.
It is mainly used in miniature lamps, small doorway lights, passage lighting, decorative lights and compact outdoor fixtures that require tiny size and flexible light control.
