XH7132 Vertical 3 Axis CNC Milling Machine For Metal 6000rpm 8000rpm High Precision
Three-axis transmission adopts Taiwan ground double nut ball screw, compact structure, smooth movement, and high accuracy. The base adopts large water tray structure casting, which has good waterproof performance.
- High Precision Hard guideway and screw.
- Taiwan-made spindle unit, 6000, 8000rpm speed available.
- Taiwan OKADA Funnel Type 10T/12T ATC can be choosen.
- Reliable Control System: Fanuc, Mitsubishi, GSK.
- Automatic Central Lubrication System.
|
PROJECT |
UNIT |
XH7132 |
|
|
Spindle taper/Spindle unit spindle diameter |
/ |
BT40/120 |
|
|
Spindle speed |
rpm |
8000 |
|
|
Spindle servo motor |
kw |
5.5 |
|
|
X/Y/Z axis feed motor |
N.M |
X/Y:6;Z:15 |
|
|
X-axis travel |
mm |
600 |
|
|
Y-axis travel |
mm |
400 |
|
|
Z-axis travel |
mm |
500 |
|
|
Spindle nose to table |
mm |
120-620 |
|
|
Spindle center to column surface distance |
mm |
440 |
|
|
Table size(L*D) |
mm |
1000*320 |
|
|
T-slot(Width*Number*Pitch) |
mm |
12*3*105 |
|
|
Max. Table load |
kg |
300 |
|
|
Fast traverse(X/Y/Z) |
m/min |
X/Y/Z 24 |
|
|
Screw diameter/pitch(X/Y/Z) |
mm |
32/12 |
|
|
Rail form |
mm |
Linear guide |
|
|
Positioning accuracy |
mm |
0.008 |
|
|
Repeat positioning accuracy |
mm |
0.005/300 |
|
|
System |
/ |
Optional |
|
|
Tool library |
/ |
(HAT)BT40-T12/16 (DISC)BT40-T16 |
|
|
AIR FORCE SOURCE (PRESSURE/CAPACITY) |
MPA |
0.6 |
|
|
Weight |
kg |
2400 |
|
Three-axis transmission adopts Taiwan ground double nut ball screw, compact structure, smooth movement, and high accuracy. The base adopts large water tray structure casting, which has good waterproof performance.
CNC milling machines excel in precision, delivering tight tolerances (often within ±0.005mm) that manual machining cannot match, ideal for high-quality components. They boost efficiency by running 24/7 with minimal human intervention, cutting production cycles significantly. Their repeatability ensures identical parts in batch production, eliminating human errors. Complex geometries—such as 3D contours and intricate cavities—are easily achieved, a feat beyond conventional tools. Additionally, flexibility allows quick program adjustments for different parts, reducing setup time and adapting seamlessly to diverse manufacturing needs.
