Wafer Type Lug Valve Duplex 2205 Triple Offset Valve PN10 For Oil And Gas
Wafer Type PN10 Duplex 2205 Triple Offset Butterfly Valve for Oil & Gas
Product Features
Specifically engineered for harsh operating conditions such as low-pressure strong acids and high-chloride salt spray. Featuring a 4A duplex stainless steel base with exceptional corrosion resistance, it is fully compatible with PN10 low-pressure systems. The combination of an all-metal hard seal and a triple-offset design ensures long-term, stable, and trouble-free operation with zero leakage.
Product Advantages
● Features a wafer-type, slim-profile design; the flangeless construction significantly reduces weight and volume, saving installation space and pipeline support costs.
● All flow-through components, including the valve body and disc, are made of 4A duplex stainless steel (ASTM A995 Gr. 4A). The ferritic-austenitic duplex microstructure provides high strength and excellent corrosion resistance, with a pitting resistance equivalent (PREN) of over 35, effectively resisting pitting and stress corrosion cracking in corrosive media such as seawater, high-chloride brine, organic acids, and acidic/alkaline solutions.
● Based on the principle of three-dimensional eccentric geometry, the operating torque is significantly lower than that of traditional valves, making it easily compatible with manual, electric, and pneumatic actuators.
Design Standards
|
Technique request |
Standard |
|
Design Standard |
API 609, ASMEB16.5,EN593,GB/T12238,JB/T8527 |
|
Face to Face Standard |
ASME B16.10 |
|
Connection standard |
ASME B 16.5,ASME B 16.47,GOST33259,EN1092-1,HG/T20592,JIS B2220,GB/T9113,GB/T9124.1 |
|
Test & Inspect Standard |
API 598,EN 12266,GB/T13927 |
|
Nominal Dimension |
2”- 100” |
|
Connection type |
BW, RF, RTJ. FF |
|
Fungtive Emission Testing |
ISO 15848 |
Product detail
Application
Chemical and Petrochemical Industries,Power Generation, Water Treatment and Environmental Protection,Metallurgy and Shipbuilding.
About Us
Zhejiang Yugong Fluid Technology Co., Ltd. is a comprehensive high-tech enterprise integrating production and sales. The company manufactures and operates professional butterfly valves made of stainless steel, carbon steel, titanium and other materials. Founded in 2012, the company is located in Yongjiao Oubei, the "hometown of pumps and valves in China", covering an area of 4,000 square meters and has more than 80 employees. Aiming high and forging ahead, the company looks forward to working hand in hand with new partners and walking all the way!
Our Workshop
|
|
|
|
|
|
|
|
|
F&Q
| Q: Are you trading company or manufacturer ? |
| A: We are a factory. |
| Q: How long is your delivery time? |
| A: According to the order,10~60days. |
| Q: Do you provide samples ? Is it free or extra ? |
| A: Yes, we could offer the sample for free charge but do not pay the cost of freight. |
| Q: What is your terms of payment ? |
| A: 30% T/T in advance ,balance before shippment. |
Customer Service
- Before signing an official contract with our customer we will help to analyze and provide professional solution based on customer project information and come out with optimum solution.
- Your inquiry related to our products or price will be replied in 24hrs.
- Keep informing our customer production process and help arrange quality checking in the factory if necessary.
- one-year warranty toproducts.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
