3.5mm 94 V0 Silicon Thermal Gap Pad For Automotive Engine Control Units 2.6w TIF5140US
3.5mm 94 V0 new developed Silicon Thermal Gap Pad for Automotive engine control units 2.6w TIF™5140US China supplied
Company Profile
Features
> Good thermal conductive: 2.6W/mK
> Naturally tacky needing no further adhesive coating
> Soft and Compressible for low stress applications
Applications
> Cooling components to the chassis of frame
> High speed mass storage drives
> Heat Sinking Housing at LED-lit BLU in LCD
> LED TV and LED-lit lamps
> RDRAM memory modules
> Micro heat pipe thermal solutions
> Automotive electronics
> Telecommunication hardware
> Handheld portable electronics
> Semiconductor automated test equipment (ATE)
|
Typical Properties of TIF™5140US Series
|
||||
|
Color
|
Violet |
Visual | Composite Thickness | hermalImpedance @10psi (℃-in²/W) |
|
Construction &
Compostion |
Ceramic filled silicone rubber
|
*** | 10mils / 0.254 mm | 0.36 |
| 20mils / 0.508 mm | 0.41 | |||
|
Specific Gravity
|
2.95 g/cc | ASTM D297 |
30mils / 0.762 mm |
0.47 |
|
40mils / 1.016 mm |
0.52 | |||
|
Thickness
|
3.5mmT | *** |
50mils / 1.270 mm |
0.58 |
|
60mils / 1.524 mm |
0.65 |
|||
|
Hardness
|
18 Shore 00 | ASTM 2240 |
70mils / 1.778 mm |
0.72 |
|
80mils / 2.032 mm |
0.79 | |||
|
Tensile Strength
|
45 psi |
ASTM D412 |
90mils / 2.286 mm |
0.87 |
|
100mils / 2.540 mm |
0.94 | |||
|
Continuos Use Temp
|
-40 to 160℃ |
*** |
110mils / 2.794 mm |
1.01 |
|
120mils / 3.048 mm |
1.09 | |||
|
Dielectric Breakdown Voltage
|
>5500 VAC | ASTM D149 |
130mils / 3.302mm |
1.17 |
|
140mils / 3.556 mm |
1.24 | |||
|
Dielectric Constant
|
4.3 MHz | ASTM D150 |
150mils / 3.810 mm |
1.34 |
|
160mils / 4.064 mm |
1.42 | |||
|
Volume Resistivity
|
4.2X1013 Ohm-meter | ASTM D257 |
170mils / 4.318 mm |
1.50 |
|
180mils / 4.572 mm |
1.60 | |||
|
Fire rating
|
94 V0 |
equivalent UL |
190mils / 4.826 mm |
1.68 |
|
200mils / 5.080 mm |
1.77 | |||
|
Thermal conductivity
|
2.6 W/m-K | ASTM D5470 | Visua l/ ASTM D751 | ASTM D5470 |
Standard Thicknesses:
0.020" (0.51mm) 0.030" (0.76mm)
0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)
0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)
0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)
0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)
0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)
0.190" (4.83mm) 0.200" (5.08mm)
Consult the factory to alternate thickness.
Standard Sheets Sizes:
8" x 16"(203mm x 406mm)
TIF™ series Individual die cut shapes can be supplied
