Built in Steam Generator Autoclave Steam Sterilizer With Steam Traps and Diaphragm Valve
Built in Steam Generator Autoclave Sterilizer Machine With Steam Traps and Diaphragm Valve
Specifications
- The chamber is completely made of AISI 304 stainless-steel.
- AISI 304 stainless steel piping is connected with tri-clamp connections.
- The machine body is insulated with ceramic material and with an external cladding of stainless steel.
- Rectangular chamber to safe space.
- Designed to maximize performance and minimize cycle time and energy use.
- Possibility to have the service area on the left or on the right side of the autoclave.
- Flexibility configuration: hinged door left or right, pit mounted or floor loaded.
- The control system monitors, records, and controls the operation of the equipment.
- Customized cycle according to client requirements.
- Door seal system guaranteed for 3 years operational use without lubrication.
- Drain cooling system available.
- Airtight or bio-seal separation.
- 304 stainless steel Built in steam generator
Main Parameters
|
Model |
MDR-0.24 |
|
Door number |
Single or double door(s) |
|
Door type |
Motorized Hinge Door |
|
Chamber and jacket material |
SS304 / Steel |
|
Chamber volume |
240 liters |
|
Chamber Size |
600*600*670mm |
|
Overall Size |
1350*1800*1010mm |
|
Net Weight |
700kg |
|
Steam |
20Kg/cycle |
|
Water |
30Kg/cycle |
|
Power(KVA) |
2KVA+ 12KW for steam generator(option) |
|
Sterilization temperature rage |
105°C to 134°C |
|
Sterilization time rage |
0---99 minutes |
|
Vacuum times |
0---9 times |
|
Drying time |
0---99 minutes |
|
Quality Standards |
cGMP |
|
ISO 9001:2008 |
|
|
ISO 13485:2012 |
|
|
Sterilization items |
rubber plugs |
|
aluminum caps |
Sterilization Cycles
|
Cycle No. |
Cycle Name |
Further Details |
|
1 |
Rubber plugs |
3 times Vacuum, expose temperature 121℃, expose time 25 min, drying time 25 min. |
|
2 |
Aluminum caps |
3 times Vacuum, expose temperature 132℃, expose time 15 min, drying time 15 min. |
|
3 |
Clothing |
3 times Vacuum, expose temperature 121℃, expose time 15 min, drying time 25 min. |
|
4 |
Liquid |
15 min exchange, expose temperature 121℃, expose time 15 min, cooling time 25 min. |
|
5 |
B-D Test |
3 times Vacuum, expose temperature 134℃, expose time 4 min, drying time 3 min. |
|
6 |
Vacuum Leak Test |
Test the chamber connecting parts’ tightness effect. It’s important to ensure the sterilization effect. |
|
7 |
User Programmable |
All preset parameters can be resettable; Multiple customized programs can be set and stored by user. |
Support for Your Investment
- Medpharm is dedicated to supporting our customers from pre-sales and installation to production.
- We understand the time and financial investment made by our customers and provide a team of experienced support managers and expert engineers needed to make your project installation and validation successful.
- Support is provided throughout every stage of the development, purchase, manufacturing, delivery and installation process.
- Medpharm’s team invests great effort into understanding your requirement specification and transforms it into high-end autoclaves. We provide full support to our clients during the installation and validation of our machines at their facility.
- We provide safe autoclaves that conform to cGMP regulations and are operationally reliable thereby enabling continuity of a pharma facilities’ production workflow.
