SS304 Sliding Door With Steam Generator Horizontal Autoclaves For Research Institutes

Features

• The sterilizer is made in AISI 304 stainless steel.
• It has vertical sliding doors featuring automatic command.
• It also has a color touch screen display that shows a simple interface. The user can be identified based on the password given.
• The whole control is created from the PLC.
• It has a quick printer that has graphical registers and provides real-time results.
• Sterilization cycles are validated and standard, permitting a hundred cycles to be made.
• It can also be connected to a PC.

Introductions

In research institutes, universities and biosafety laboratories people work with highly sensitive laboratory materials requiring extremely responsible handling. Safety and reliability are vital factors in laboratory reprocessing.

Medpharm is familiar with the demands running a laboratory poses and has been providing state-of-the art solutions used in laboratories, pharmaceutical companies, biotech companies, universities and hospitals.

Technical Chart

Specifications

1. Valves & Components

All process valves are pneumatically operated piston valves, providing longer service life and less maintenance. All standard components are non-proprietary and easily sourced.

2. Steam Supply

• Built-in Electrical Steam Generator Central Steam Supply
• An automatic, integral, electrically heated steam generator mounted under the sterilizer chamber.
• The integral steam generator pressure vessel is made of stainless steel, insulated with 50 mm chloride free mineral wool enclosed in a rigid removable aluminium sheet housing. The heating elements are made of stainless steel.

3. Optional Water Saving System

Trans 'WATER SAVING SYSTEM' is a used to limit the consumption of the water utility during the process and saves around 45-75% of regular water consumption.

Our Advantages

Maximum Flexibility

Our strength is flexibility. Sterilization processes, machine apacity and the quality of performance perfectly match our customers’ sterilization goods.

We offer a wide range of chamber sizes (300 to 8,000 liters) and programs. The sterilizers are available in vertical, horizontal and one- or two-door versions subject to requirements or chamber size.

Protecting People And The Environment

There are many types of materials in laboratories, hygiene standards are extremely high. Perfect sterilization processes are the prerequisite for safety in laboratory operation. Suitable methods have to be used to validate sterilization processes in terms of the desired effect,because perfect sterilization results can only be achieved by precisely matching sterilization processes to the material to be sterilized.

Brochure load down from here

Medpharm medical large steam autoclave brochure.pdf
