Stainless Steel Sanitary Butterfly Valve High Performance Butterfly Valves For Food Machines
Price:
Contact us for the best quote
MOQ:
1 pc
Delivery Time:
1 - 2 weeks
Brand:
WLM
Product Description
Manual Type 304 or 316L Size 1/2"-6" Sanitary Butterfly Valves for Food Machines
Features:
- Quick and simple open / close function
- Low fluid resistance suitalbe for frequent use
- Good sealing capability for long service life
- High-precision CNC lathes utilized to finish valve body
- Use of quality stainless steel and food grade rubber to meet all sanitary standards
- Valve body diameter exactly matches pipe system for large flow
Configurations:
Specifications:
| Driving Mode: | Manual |
| Connection Ends: | Welding, Thread, Clamp, Quick Install, Flange, all available |
| Quantity: | Single piece type, double pieces type, triple pieces type available |
| Size: | DN10 ~ DN200 , 1/2" ~ 8", Φ19 ~ Φ102, all other sizes can be customized |
| Material: | SUS304, or SUS316L |
| Seal Material: | Free choice among EPDM, PTF E, FPM or NBR |
| Working Pressure: | Low Pressure (Pn<1.6mpa) |
| Working Temperature: | -10℃ ~ +95℃ |
| Surface Process: | Matt |
| Connection Standard: | 3A, DIN, ISO, SMS, RJT, IDF |
Main Types:
A. Sanitary butterfly vavle with Pull-rod handle:
1. 4 open and close multifunction positions
2. Handle operation to lock valve mechanically in a certain position, to control media flow
3. Low cost, simple operation
B. Sanitary butterfly valve with multiple position gripper handle:
1. 12 open and close multifunction positions
2. Handle can be adjusted by 15 degree angle, to lock valve mechanically in a certain position, control media flow
3. Flow control can be more accurate
