4 Gear Pull Handle Sanitary Butterfly Valve With Thread And Weld Connection

Name: 4 Gear Pull Handle Sanitary Butterfly Valve With Thread And Weld Connection
Brand: Linch Machinery Co. Ltd.

Price Negotiable

Price: Negotiable

MOQ: > 1 pc

Delivery Time: 7 - 14 days

Brand: WLM

Product Description

4 Gear Pull Handle Sanitary Hygienic Stainless Steel Thread and Weld Connection Butterfly Valves

Features:

Hygienic grade for food, beverage, beer, pharmacy, biotechnology industries
Rotate manual by 90 degrees to close or open the valve
Simple structure, small rotation torque with good flow adjustion and sealing function
Very low resistance when valve is completely open
Fast action on flow control when valve is opened by 15 to 70 degrees
Very competitive application in big sized pipe systems

Our Competitive Advantages:

We use best quality EPDM gasket to ensure anti-aging, anti-corrosion functions
We use advanced CNC machine imported from Japan to ensure accurate valve dimension
Manual handle grooved with nylon ball or sleeve for easier opening and close
The valve diameter is equal to pipe size to ensure as large flow ability as possible
We design manual handle position adjustable by every 15 degrees
We perform strict mechanical property test and sealing test on each valve
We do sampling lifetime cycling test out of each batch, to ensure lifetime

Specifications:

Port Size	DN15 - DN150 (DIN) , Ф19 - Ф108 (ISO) or custom on request
Operation Mode	4 gear pull handle, or 12 gear gripper handle
Valve Body Material	SUS304, SUS316L, machined by advanced CNC equipment
Sealing Gasket	Silicone for size Ф63.5-Ф108, EPDM for all sizes
Working Temperature	-10 to +100 degrees centigrade
Working Pressure	Up to 10 bar
Connection Ends	One side weld, the other side thread
Dimension Standard	ISO, DIN, IDF, 3A, SMS etc.
Medium	Beer, red Wine
Surface Treatment	Mirror Polished for medium contact surface
Packing:	Carton or plywood case
