3.0W/MK Thermal Gap Filler 27shore00 For Heat Sinking Housing At LED-Lit BLU In LCD
3.0W/mK professional factory thermal gap filler 27shore00 For Heat Sinking Housing at LED-lit BLU in LCD
Company Profile
With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.
<Outstanding thermal performance
<Fiberglass reinforced for puncture, shear and tear resistance
<Electrically isolating
<Heat Sinking Housing at LED-lit BLU in LCD
<LED TV and LED-lit lamps
<Micro heat pipe thermal solutions
<Automotive engine control units
<Memory Modules
<Mass storage devices
|
Typical Properties of TIF 5120-30-11U
|
|||
|
Product Name
|
TIF5120-30-11U Series
|
||
|
Colour
|
Grey | ||
|
Construction & Compostion
|
Ceramic filled silicone rubber
|
||
|
Specific Gravity
|
3.0g/cc
|
||
|
Dielectric Constant@1MHz
|
4.4 MHz
|
||
|
Hardness
|
27Shore 00
|
||
|
Flame Rating
|
94 -V0
|
||
|
Continuos Use Temp
|
-40to 160℃
|
||
|
Dielectric Breakdown Voltage
|
>5500 VAC
|
||
|
Thermal conductivity
|
3.0 W/mK
|
||
|
Thickness
|
3.0mmT | ||
Packaging Details & Lead time
The packaging of thermal pad
1.with PET film or foam-for protection
2. use Paper Card To Separate Each Layer
3. export carton inside and outside
4. meet with customers' requirement-customized
Lead Time :Quantity(Pieces):5000
Est. Time(days): To be negotiated
Standard Sheets Sizes:
8" x 16"(203mm x 406mm)
TIF™ series Individual die cut shapes can be supplied.
