JGS1 JGS2 JGS3 Quartz Glass Optical Window Used For IR Windows
Quartz Glass Window
Processing Capacity
Capable to realize the complete processes in optical design, instrument design, component high-precision molding,
planar processing, spherical processing, aspheric processing, coating, etc.
Applications
Photoelectric information; aerospace; new energy; nuclear power and nuclear energy equipment and other fields.
Performance
● The material is quartz glass, which can be used for IR windows made of quartz glass with the absorption band of
2.7μm.
● The surface reflection loss varies with the refractive index of the material when light penetrates the window .
Features
|
Quartz Glass Window |
|
| Model | Window-QG-X |
| Material |
JGS1 / JGS2 / JGS3 quartz glass |
| Surface precision | λ/20 |
| Parallelism | ≤5 seconds |
| Surface quality | 10-5 |
| Dimensional tolerance | ±0.1mm |
| Maximum Dimension | Ф1200mm |
Our Advantages
We are manufacturer.
Mature process.
Reply within 24 working hours.
