4500N Ironcore Linear Motor 4m/S Cogging Synchronous Low Power Consumption
Price:
Negotiable
MOQ:
20
Delivery Time:
5-8work days
Brand:
HXC
Product Description
Ironcore Linear Motors EC177WC series Very large force applications Force range Fc_wc 1500-5850N Fp_wc 2700-10125N
Ironcore Linear Motors EC177WC series Very large force applications Force range Fc_wc 1500-5850N Fp_wc 2700-10125N
Product advantages:
Water cooled/Air cooled are optional, width of motor setup <185mm
Very compact size, and with extremely high force density
High acceleration, high speed, submicron positioning accuracy and low power consumption
Very low attraction force and cogging
Very good heat dissipation performance
Any length of high flflex chain cables for motors can be made
electrical
| Parameter | Remarks | Symbol | Unit | EC177WC-12 | EC177WC-15 | EC177WC-18 | EC177WC-24 | EC177WC-30 | EC177WC-45 | ||||||
| Ultimate Current | Magnet@25°C | lu | Arms | 13.1 | 26 | 13.5 | 33 | 20 | 41 | 27 | 52 | 28 | 66 | 41 | 98 |
| Peak Current | Magnet@25°C | lp | Arms | 10 | 20 | 11 | 25 | 15 | 31 | 20 | 40 | 21 | 50 | 31 | 75 |
| Continuous Current Water cooled | Coil@110°C | lc | Arms | 5.5 | 11 | 6 | 14 | 8 | 17 | 11 | 22 | 12 | 29 | 18 | 42 |
| Continuous Current Air cooled | Coil@110°C | lc | Arms | 4.3 | 9 | 4.3 | 11 | 6.5 | 13.4 | 9 | 18 | 9 | 22 | 13.4 | 32 |
| Back EMF | Phase-Phase peak | Bemf | V/M/s | 228 | 114 | 274 | 114 | 228 | 110 | 228 | 114 | 274 | 114 | 228 | 114 |
| Resistance Per Phase | Coil@25°C | Rph | Ω | 9.1 | 2.27 | 10.8 | 1.82 | 6.06 | 1.45 | 4.54 | 1.14 | 5.4 | 0.91 | 3.61 | 0.61 |
| Induction Per Phase | l<0.63lp | Lph | Mh | 77.35 | 19 | 92 | 15 | 52 | 12 | 39 | 10 | 46 | 8 | 31 | 5 |
| Electrical Time Constant | Coil@25°C | Te | Ms | 8.5 | 8.5 | 8.5 | 8.5 | 8.5 | 8.5 | 8.5 | 8.5 | 8.5 | 8.5 | 8.5 | 8.5 |
| Power Loss | All coils | Pc | W | 713 | 713 | 891 | 891 | 1011 | 1011 | 1347 | 1347 | 1684 | 1684 | 2527 | 2527 |
thermal
| Parameter | Remarks | Symbol | Unit | EC177WC-12 | EC177WC-15 | EC177WC-18 | EC177WC-24 | EC177WC-30 | EC177WC-45 | ||||||
| Thermal Resistance | Coils to mount. Sfc. | Rth | °C/W | 0.13 | 0.13 | 0.12 | 0.12 | 0.11 | 0.11 | 0.09 | 0.09 | 0.07 | 0.07 | 0.03 | 0.03 |
| Temp. Sensor | PTC 1kΩ/NTC | ||||||||||||||
Mechanical
| Parameter | Remarks | Symbol | Unit | IC177WC-12 | IC177WC-15 | IC177WC-18 | IC177WC-24 |
IC177WC- 30 |
IC177WC- 45 |
||||||
| Coil Unit Weight | ex.cables | W | kg | 7 | 7 | 9 | 9 | 12 | 12 | 16 | 16 | 18 | 18 | 27 | 27 |
| Coil Unit Length | ex.cables | L | Mm | 248 | 248 | 296 | 296 | 336 | 336 | 440 | 440 | 568 | 568 | 840 | 840 |
| Motor Attraction Force | Rms@0A | Fa | N | 5100 | 5100 | 6225 | 6225 | 7350 | 7350 | 6800 | 6800 | 12450 | 12450 | 18675 | 18675 |
| Magnet Pitch | N-N | T | mm | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 |
| Power Cable Type | length 0.5m(3m,5m,10m optional) | Diameter | mm(mm2) | 10.1(4G2.5mm2 AWG14) |
12.1 (4G4mm2 AWG14) |
14.7 (4G 6mm2) |
|||||||||
| Sensor Cable Type | length 0.5m(3m,5m,10m optional) | Diameter | mm(mm2) | 4.9(4*0.14mm2 AWG26) | |||||||||||
| Cable life | Minimum | Cycles | >5,000,000 | >3-5millions | |||||||||||
| Bending Radius Static | Minimum | mm | ≥4xφ | ≥5xφ | |||||||||||
| Bending Radius Dynamic | Minimum | mm | ≥7.5xφ | ≥10xφ | |||||||||||
Product dimension drawing:
