Low speed High Torque Motor DDSM33 Adopts High Precision Photoelectric Sensor
DDSM33 Series DC Torque Motors Adopts High-Precision Photoelectric Sensor
DC Torque Motor specification
| Type | Peak Standstill | Max.no-load | Cont.Standstill | rotary inertia (Kg.m2*10-5) |
iron core (mm) |
||||
| Torque | Current | Voltage | Torque | Current | Voltage | ||||
| N.M | A | V | r/min | N.M | A | V | |||
| ≥ | ±12.5% | ±12.5% | ±10% | ≥ | ±12.5% | ±12.5% | |||
| DDSM33-01A | 3.5 | 15 | 80 | 2550 | 0.48 | 2 | 5.4 | 7.21 | 10 |
| DDSM33-01B | 1.12 | 62 | 24/27 | 1200 | 0.42 | 2.3 | 9 | 7.21 | 10 |
| DDSM33-01C | 1.04 | 2.88 | 48 | 1200 | 0.43 | 1.2 | 20 | 7.21 | 10 |
| DDSM33-01D | 32 | 47 | 24/27 | 3200 | 0.4 | 6 | 3.1 | 7.21 | 10 |
| DDSM33-02A | 2.12 | 15 | 80 | 4000 | 1.13 | 8 | 5.3 | 14.49 | 20 |
| DDSM33-02B | 2.04 | 30 | 24/27 | 2750 | 1 | 15 | 2.43 | 14.49 | 20 |
| DDSM33-02C | 1.88 | 5.2 | 24/27 | 600 | 1.09 | 3 | 13.86 | 14.49 | 20 |
| DDSM33-02D | 22 | 4 | 48 | 800 | 1.03 | 1.9 | 22.5 | 14.49 | 20 |
| DDSM33-03A | 4.7 | 4.23 | 80 | 650 | 1.64 | 1.5 | 28 | 21.78 | 30 |
| DDSM33-03B | 4.57 | 8.4 | 48 | 800 | 1.63 | 17 | 21.78 | 30 | |
| DDSM33-03C | 4.35 | 25 | 48 | 2500 | 1.57 | 9 | 4.9 | 21.78 | 30 |
| DDSM33-03D | 4.35 | 15 | 48 | 1500 | 1.45 | 5 | 8.6 | 21.78 | 30 |
| DDSM33-03E | 5 | 9 | 24/28 | 380 | 1.5 | 2.7 | 7.4 | 21.78 | 30 |
| DDSM33-03F | 3.5 | 5.5 | 24/28 | 300 | 1.5 | 2.35 | 10.3 | 21.78 | 30 |
Q: How to order?
A: send us inquiry → receive our quotation → negotiate details → confirm the sample → sign contract/deposit →mass production →cargo ready → balance/delivery → further cooperation
Q: Which shipping way is available?
A: DHL, UPS, FedEx, EMS,Sea are available. The other shipping ways are also available, please contact us if you need ship by the other shipping way.
Q: How long is the deliver[Producing] and shipping?
A: Deliver time depends on the quantity you order. usually it takes 15-25 working days.
Q: My package has missing products. What can I do?
A: Please contact our support team and we will confirm your order with the package contents.We apologize for anyinconveniences.
Q: How to confirm the payment?
A: We accept payment by T/T, PayPal, the other payment ways also could be
accepted,Please contact us before you pay by the other payment ways. Also 30-50% deposit is available, the balance money should be paid before shipping.
