Low Speed High Torque Motor 130NM Stable Operation Quiet High Torque Motor
Price:
Negotiable
MOQ:
10
Delivery Time:
5-8work days
Brand:
HXC
Product Description
NH430LYX DC Torque Motor Quiet Stable Operation Compact Design Strong Adaptability
NH430LYX DC Torque Motor Quiet Stable Operation Compact Design Strong Adaptability
• High torque inertia ratio, fast start / stop and high acceleration；
• High torque power ratio, low power input requirements；
• Low electrical time constant for excellent command response at all operating speeds；
• Linear torque response to input current and speed, no dead angle；
Application:
High precision positioning system, high-precision ultra-low speed high torque speed control system (one tenth of a degree per second), servo control system, seeker, steering gear system, flight control system, ship, aircraft, automobile power assist system, tank and armored vehicle braking system, infrared optical system, robot and multi degree of freedom manipulator, heart lung machine, monocrystal furnace, UAV, weapon fire control system, precision turntable, high-precision measurement and control platform Peristaltic pump, engine throttle control of
generator set, CNC machine tools, experimental equipment, ribbon products used in winding or tension components, etc.
specification
| Type | Peak Standstill | Nlax.no-load | Cont. Standstill | size | ||||
| Torque | Current | Voltage | Torque | Current | Voltage | |||
| N.M | A | r/min | N.m | A | V | L(mm) | ||
| > | ±12.5% | ±10% | ≥ | ±12.5% | ||||
| NH430LYX-M130-E60 | 130 | 9 | 60 | 34 | 72.6 | 5 | 33.2 | 30 |
| NH430LYX-M140-E48 | 140 | 12.7 | 48 | 36 | 66.5 | 6 | 22.9 | 30 |
| NH430LYX-M215-E60 | 215 | 24.3 | 60 | 54 | 72 | 8 | 19.75 | 30 |
| NH430LYX-M310-E60 | 310 | 29.2 | 60 | 45 | 106.6 | 10 | 20.6 | 42 |
| NH430LYX-M295-E80 | 295 | 20.6 | 80 | 45 | 116 | 8 | 31 | 42 |
| NH430LYX-M173-E80 | 173 | 7.15 | 80 | 27 | 109 | 4.5 | 50.4 | 42 |
| NH430LYX-M440-E110 | 440 | 20.3 | 110 | 40 | 199.3 | 9 | 48.9 | 60 |
| NH430LYX-M498-E90 | 490 | 30 | 90 | 45 | 166 | 10 | 30 | 60 |
| NH430LYX-M610-E130 | 610 | 18.4 | 130 | 32 | 165 | 8 | 56.5 | 90 |
| NH430LYX-M820-E130 | 820 | 33.3 | 130 | 44 | 250 | 10 | 39.2 | 90 |
| NH430LYX-M525-E90 | 525 | 19.5 | 90 | 28 | 170 | 10 | 46.2 | 90 |
| NH430LYX-M918-E110 | 918 | 33.2 | 110 | 32 | 359 | 13 | 43.2 | 120 |
| NH430LYX-MI200-E110 | 1200 | 44 | 110 | 32 | 456 | 16.5 | 42 | 150 |
| NH430LYX-M1450-E110 | 1450 | 50 | 110 | 33 | 525 | 19 | 41.9 | 180 |
| NH430LYX-M829-E130 | 829 | 14.3 | 130 | 18 | 523 | 9 | 82 | 180 |
| NH430LYX-M1720-E90 | 1720 | 72 | 90 | 30 | 654 | 27 | 34 | 210 |
| NH430LYX-M1060-E90 | 1060 | 27.4 | 90 | 19 | 620 | 16 | 52.6 | 210 |
| NH430LYX-M2050-E130 | 2050 | 64 | 130 | 32 | 730 | 22 | 45 | 240 |
NH430LYX Sectional outline drawing of series sine wave brushless DC torque motor
Application area
