High Torque Motor 105mm OD Direct Drive Torque Motor High Dynamics Silent DC Motor
Torque Medium Motors High Dynamics And Accuracy Low Vibration Silent Long Service Life
Torque Medium Motors High Dynamics And Accuracy Low Vibration Silent Long Service Life
Performance
| Parameter | Remarks | Symbol | Unit | TM105-17 | TM105-25 | TM105-34 | TM105-60 | TM105-92 | ||||||
| Winding Type | N | Y | Z | N | Y | Z | N | Y | Z | N | Y | |||
| Motor type | 3 phases synchronous Ironcore 230Vac rms (320Vdc) | 380Vac rms (600Vdc) | ||||||||||||
| Peak torque | Magnet@25°C | Tp | Nm | 3.5 | 3.96 | 3.96 | 7.32 | 9 | 8.28 | 12.72 | 13.56 | 12.48 | 34 | 56 |
| Continuous torque | Coil@120°C | Tc | Nm | 1.7 | 1.7 | 1.7 | 3.8 | 4 | 4 | 6.5 | 6.2 | 6.2 | 14.4 | 24 |
| Maximum Speed | @Tc@48V | nmax | mrpm | 5879 | 10583 | 17638 | 2940 | 5345 | 9203 | 1654 | 3528 | 6047 | 1157 | 1323 |
| Motor Torque Constant | Kt | Nm/Arms | 0.36 | 0.2 | 0.12 | 0.72 | 0.4 | 0.23 | 1.28 | 0.6 | 0.35 | 3.43 | 3 | |
| Motor Constant | Coils@25°C | Km | N2/W | 0.025 | 0.024 | 0.027 | 0.069 | 0.07 | 0.073 | 0.143 | 0.125 | 0.131 | 0.455 | 0.493 |
Electrical
| Parameter | Remarks | Symbol | Unit | TM105-17 | TM105-25 | TM105-34 | TM105-60 | TM105-92 | ||||||
| Peak Current | Magnet@25°C | lp | Arms | 4.7 | 8.4 | 14 | 5.3 | 10.1 | 17.4 | 5.1 | 10.4 | 17.8 | 4.2 | 8 |
| Max.Continuous Current | Coil@110°C | lc | Arms | 31 | 17 | 10 | 62 | 34 | 20 | 110 | 52 | 30 | 30 | 258 |
| Back EMF Phase to Phase peak | 25℃+/-10% | Kep | V/krpm | 31 | 17 | 10 | 62 | 34 | 20 | 110 | 52 | 30 | 295 | 258 |
| Back EMF Phase to Phase RMS | C25℃+/-10% | Ke | V/krpm | 22 | 12 | 7 | 44 | 24 | 14 | 78 | 37 | 21 | 209 | 183 |
| Resistance Per Phase | Coil@25°C | Rph | Ω | 1.75 | 0.55 | 0.18 | 2.5 | 0.75 | 0.24 | 3.81 | 0.96 | 0.31 | 8.62 | 3.26 |
| Induction Per Phase | I<0.63lp | Lph | Mh | 3.5 | 1.16 | 0.36 | 5.25 | 1.73 | 0.53 | 10.29 | 2.41 | 0.78 | 32.76 | 13.04 |
| Electrical Time Constant | Coil@25°C | Te | Ms | 2 | 2.1 | 2 | 2.1 | 2.3 | 2.2 | 2.7 | 2.5 | 2.5 | 3.8 | 4 |
| Max. Continuous Power Loss | All coils | Pc | W | 148.6 | 151.4 | 137.6 | 277.3 | 298.4 | 283.1 | 380.8 | 405.8 | 386.8 | 592.5 | 813.7 |
| Poles | Nmag | nr | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |
Product dimension drawing:
Product testing
Application area
FAQ:
1.How can I get the price?
-We usually quote within 24 hours after we get your inquiry(Except weekend and holidays). If you are very urgent to get the price, please email us or contact us in other ways so that we can offer you a quote.
2. Can I buy samples placing orders?
-Yes.Please feel free to contact us.
3.What is your lead time?
-It depends on the order quantity and the season you place the order.
Usually we can ship within 7-15 days for small quantity,and about 30 days for large quantity.
4.What is your payment term?
-L/C, T/T, Western Union
5.What is the shipping method?
-It could be shipped by sea,by air or by express(EMS,UPS,DHL and ect).Please confirm with us before placing orders.
