Compliant or special couplings are not required, so the Rotor & Stator can simply be fixed directly to the host product. Precise mechanical mounting is not necessary to achieve high measurement performance and there are no bearings. The measurement performance stated in this Product Guide is guaranteed provided that the IncOder is installed as per its installation tolerances.
Environmental Data
| INC-x-58 | ||
| Operating Temp. |
Minus 45 to +85 Minus 60 to +85Celsius for 12VCT & 24VCT Product Option. Minus45 to +105Celsius max . for 5HT Product Option Operation outside limits to be qualified by user . |
Celsius |
| Storage Temp. | Minus 55 to +125 (Minus 60 to +125 for 24CT Product Option) | Celsius |
| Temperature Shock | MIL-STD-810G, Method 503.5, Procedure I-B (T1=-40 oC, T2=55 oC .) | |
| IP Rating - Rotor & Stator |
IP67 for <60 minutes & 1m depth (Installed with mechanically protected connector or AFL1-5 or VFL1-5 Product Options) For additional protection for long term immersion at depth, specify product option AFL2-52 or VFL2-52 Product Option For immersion at depths of >100m select Extended Range High Pressure Option |
|
| IP Rating - Connector | IP50 (ACx or RCx Product Option) . See Section 4.7 for IP rating of AFLx & VFLx Product Option | |
| Humidity | RH 0-99% standard. Select Extended Range Option C & appropriate connector for condensing humidity or long term immersion | |
| Salt Fog | (Installed with protected cable/connector or any integral axial cable) Complies with DEF STAN 00-35 Pt. 3 Iss. 4, Test CN2 Salt Mist Test. Select Extended Range Option C and appropriate connector for environments with significant exposure to salt fog | |
| Bio Hazards | (Installed with protected cable/connector or any integral axial cable) Complies with DEF-STAN 00-35 Pt. 4 Iss. 4 Section 11 (Hazards) | |
| Induced Dust & Sand |
Complies with DEF STAN 00-35 Pt 3 Iss 4, Test CL25 (Turbulent Dust) Cat 1. Select Extended Range Option C and appropriate connector for environments with abrasive dust or sand. |
|
| Mechanical Impact Resistance | IK07 - when installed - suitable for mechanical impacts from objects of >200grams from 1m height | |
| Shock |
IEC 60068-2-27 100g for 11ms - axial & radial - suitable for most airborne, marine & armoured vehicles MIL-STD-810G, Method 516.6, Procedure I- Functional Shock - axial and radial - 40 g 11 ms, sawtooth waveform For more extreme or prolonged conditions specify Extended Product Option G & preferably Integral Axial Cable |
|
| Vibration |
IEC 60068-2-6 20g for 10-2000Hz - axial and radial - suitable for most high vibration & airborne environments MIL-STD-810G, Method 514.6, Procedure I - axial and radial - Category 20, for tracked vehicles For more extreme or prolonged conditions specify Extended Product Option G and preferably Integral Axial Cable |
|
| Environmental pressure range | 0 to 7 (i.e. vacuum to 7). See Extended Product Range High Pressure Option for higher operating pressures | Bar |
| Max. permissible press. change rate | 1 | Bar/second |
| EMC Radiated Susceptibility | (Installed) Complies with IEC 61000-6-2 - suitable for fitment in harsh EMC environments | |
| EMC Radiated Emissions | (Installed) Complies with IEC 61000-6-4 - suitable for fitment adjacent to EMI sensitive devices | |
| Materials - all Product Options | ||
| Rotor & Stator Housings |
Standard range:- Al. alloy (6061-T6 or 6084-T6) with SurTec650. Sensor surfaces: FR4 grade epoxy Product Option A or S:- Alocrom finish al. alloy (6061-T6 or 6084-T6) . Sensor surfaces: FR4 grade epoxy |
|
| Connector (ACx or RCx Product Option) | PPS with Stainless Steel Screw Fixings and Gold & Tin Electrical Connections | |
| Miscellaneous - all Product Options | ||
| Mass Shaft Clamp Rotor (max.) | 43 | grams |
| Mass Plain Rotor (max.) | 32 | grams |
| Mass Servo Clamp Stator (AC1 ) | 43 | grams |
| Mom. of Inertia Shaft Clamp Rotor (max.) | 2.0E-05 | Kgm2 |
| Mom. of Inertia Plain Rotor (max.) | 1.8E-05 | Kgm2 |
| MTBF | 0.22 failures per 1M hours based on MIL- HBK-217+ method for ground military vehicles at 20Celsius average | |
| MTBF | 0.35 failures per 1M hours based on MIL- HBK-217+ method for naval sheltered at 35Celsius average | |
| Hazardous materials | Standard range - Hazardous materials not used. RoHS compliant. RoHS certificate available. REACH statement available. | |
| Outgassing materials | Complies with NASA class'n as low outgas matl. with TML <1% & CVCM <0.1% at 125C & 24hrs vacuum to ASTM E-595-90 | |
| ITAR classification | Not ITAR controlled. No ITAR components | |
| Approvals | Flammability Rating UL94V-0. Standard range - RoHS compliant - RoHS certificate available. REACH statement available. | |
| Marking | Zettlex, logo, CE & UL94V-0 printed on Rotor & Stator faces; Serial No. labelled on exterior diameter of Stator housing Extended Product Range Option E - engraved serial number and part number on exterior faces of Stator & Rotor | |
| Country of Manufacture | UK | |
| Export Licence Requirements | Not required for standard product options | |
