RS 485 Magnetic Rotary Encoder Communication Rotary Encoder Sensor Communication

Name: RS 485 Magnetic Rotary Encoder Communication Rotary Encoder Sensor Communication
Brand: Shenzhen Haixincheng Technology Co.,Ltd

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: 5-8 work days

Brand: HXC

Product Description

Inductive Rotary Encoder Hight Resolution Communication RS-485 BISS-C SSI

Inductive Rotary Encoder Hight Resolution Communication RS-485 BISS-C SSI

1.The encoder has the following characteristics:

Good environmental resistance, dust, water and oil resistance, low installation environment requirements, and no clean room installation and operation.
The inductive encoder is an area sensor (relative to a point sensor) and can tolerate a certain installation deviation.
Inductive encoder has high safety and has no enrichment effect on magnetic dust compared with magnetic sensor. It is widely used in key parts of automobile, military industry and aerospace fields.
The modulation characteristics of the inductive encoder can better suppress the 1 / f noise of the circuit, and the long-term stability of the position is good.
Inductive encoder, no fragile materials such as glass code disk, high seismic resistance.
Inductive encoder is suitable for low temperature environment.

2.Encoder specification

Integrated package

	EIS 16	EIS 25	EIS 37	EIS 40	EIS 58	EIs 9o	EIS 130
External diameter	16	25	37	40	58	90	130
Internal diameter	4	6	10	10	20	50	90
Thickness(mm)	8	7	8	10	10	10	10
Communication	RS485/Biss -C/SSl
Maximum speed(rpm)	6000	6000	4000	4000	4000	3000	1500
Resolution (bits)	17	17/19	17/19	17/19	19/21/23	21/23	23

Package split type

	EIF37	EIF 58	EIF 75	EIF 90	EIF 100	EIF 125	EIF 150	EIF 300
External diameter	37	58	75	90	100	125	150	300
Internal diameter	8	12.5	25	40	50	75	110	250
Thickness(mm)	11.25	14.6	15.4	15.4	15.4	15.4	154	16.4
Communication	RS485/Biss -C/SSI
Maximum speed(rpm)	9000	9000	9000	7200	7200	6000	5000	4500
Resolution (bits)	17/19	19/21/23	21/23	21/23	21/23	23	23	23

Open type

	EIC25	ElC40	EIC 60	EIlC 100
External diameter	25	40	60	100
Internal diameter	10	15	25	50
Thickness(mm)	6	6	6	8
Communication	RS485/Biss -C/SSl
Maximum speed(rpm)	6000	6000	4000	4000
Resolution (bits)	17	19/21	21/23	23

3. Parameter table

General parameters		Electrical parameters
Resolving power	17 / 19 / 21 / 23 bits	Supply voltage	5V main 5%
System accuracy	0.02 ° (standard)	Current consumption	90mA
Maximum allowable speed	9000 rpm	Connector type	Shielded twisted pair
Single turn / multi turn	Single lap
Mechanical parameters		External environment
Allowable installation eccentricity	0.1mm	EMC standard	IEC6100-6-2/4
Allowable axial installation error	0.1mm	Working temperature	-45°℃-+85°℃
Rotor inertia	4.8E-O5 kgm2	Storage temperature	-55°C-+125℃
Total weight	150g	Humidity	0~99% non condensing
Od / ID / height	See specific specifications	To attack	100g 11ms
Material Science	Shell aluminum alloy	Shock	20g 10-2000Hz
		Protection level	P65

4. Naming method

A-

058-

Type: inductive type
O: photoelectric type
M: magnetoelectric type

Packaging style:
S: integrated packaging;

C: open packaging;
F: separated packaging

Occurrence mode:
A: radial outgoing line 250mm (scattered line);
B: radial outgoing line 500mm (scattered line);
C: axial outgoing line 250mm (scattered line);
C: axial outgoing line 500mm (scattered line)

Outer diameter dimension

25: 16-25mm
36: 35-40mm
58: 55-60mm
87: 80-100mm
130: 120-150mm
300: 300mm

Model output
S: SSI
B: biss-c
R: RS485 (compatible with NRZ)
O: other

Resolution: 17:17bits, 19:19bits, 21:21bits, 23:23bits
