TBSM76 Brushless Torque Motor Electromotive Low Torque Motor Waveform Torque Motor
TBSM76 Brushless Torque Motor Low Torque Ripple Excellent Sine Back Electromotive Force Waveform
TBSM76 Brushless Torque Motor Low Torque Ripple Excellent sine back electromotive force waveform
Brushless Torque Motor specification
| Type | Peak Standstill | Max.no-load | Cont.Standstill | Rated power | resistance | Back EMF Coefficient | Torque Coefficient | Moment of inertia | wight | |||||
| Torque | Current | Voltage | Torque | Current | Voltage | Torque | speed | |||||||
| Nm | A | V | r/min | Nm | A | V | Nm | r/min | Ω | v/rpm | Nm/A | Kg.m2*10-5 | Kg | |
| ±10% | ±10% | ±10% | ±10% | ±10% | ±5% | ±10% | ±10% | ±10% | ||||||
| TBSM76-15A10 | 2.66 | 7 | 48 | 1000 | 0.95 | 2.5 | 13.5 | 0.7 | 805 | 6.2 | 0.048 | 0.43 | 3.04 | 0.48 |
| TBSM76-15A20 | 5.45 | 26 | 48 | 2000 | 0.94 | 4.4 | 6.24 | 0.7 | 1800 | 1.45 | 0.024 | 0.217 | 3.04 | 0.48 |
| TBSM76-15A31 | 3.8 | 27 | 48 | 3100 | 0.95 | 6.8 | 3.85 | 0.7 | 2896 | 0.57 | 0.015 | 0.14 | 3.04 | 0.48 |
| TBSM76-15A40 | 3.5 | 30.5 | 48 | 4000 | 1 | 8.85 | 3.2 | 0.7 | 3650 | 0.39 | 0.0125 | 0.11 | 3.04 | 0.48 |
| TBSM76-15B10 | 3.7 | 17.5 | 24 | 1000 | 0.97 | 4.5 | 6.3 | 0.7 | 820 | 1.45 | 0.024 | 0.217 | 3.04 | 0.48 |
| TBSM76-15B20 | 3.0 | 29 | 24 | 2000 | 1 | 9.7 | 3.95 | 0.7 | 1920 | 0.32 | 0.011 | 0.103 | 3.04 | 0.48 |
| TBSM76-15B28 | 2.81 | 38 | 24 | 2800 | 0.95 | 12.7 | 1.99 | 0.7 | 2598 | 0.17 | 0.008 | 0.075 | 3.04 | 0.48 |
| TBSM76-31A10 | 5.85 | 15 | 48 | 1000 | 1.95 | 5 | 11.1 | 1.26 | 850 | 2.22 | 0.048 | 0.39 | 5.64 | 0.82 |
| TBSM76-31A20 | 5.82 | 30 | 48 | 2000 | 1.94 | 10 | 5.4 | 1.25 | 1854 | 0.54 | 0.024 | 0.194 | 5.64 | 0.82 |
| TBSM76-31A35 | 3.93 | 40 | 48 | 3500 | 1.77 | 18 | 3.1 | 1.15 | 3353 | 0.17 | 0.014 | 0.983 | 5.64 | 0.82 |
| TBSM76-31A26 | 7.5 | 50 | 48 | 2650 | 1.8 | 12 | 4.76 | 1.17 | 2479 | 0.4 | 0.018 | 0.15 | 5.64 | 0.82 |
| TBSM76-31B10 | 5.91 | 30 | 24 | 1000 | 1.97 | 10 | 5.36 | 1.23 | 855 | 0.54 | 0.024 | 0.197 | 5.64 | 0.82 |
| TBSM76-31B17 | 4.44 | 40 | 24 | 1750 | 2 | 18 | 3.08 | 1.25 | 1604 | 0.17 | 0.013 | 0.11 | 5.64 | 0.82 |
| TBSM76-16A10 | 7.74 | 20 | 48 | 1020 | 2.71 | 7 | 8.25 | 1.75 | 906 | 1.18 | 0.047 | 0.39 | 8.19 | 1.15 |
| TBSM76-46A15 | 7.5 | 30 | 48 | 1550 | 2.75 | 11 | 5.5 | 1.75 | 1435 | 0.5 | 0.031 | 0.25 | 8.19 | 1.15 |
| TBSM76-46A23 | 6.67 | 40 | 48 | 2300 | 2.5 | 15 | 3.53 | 1.62 | 2190 | 0.24 | 0.021 | 0.17 | 8.19 | 1.15 |
| TBSM76-46B11 | 6.67 | 40 | 24 | 1155 | 2.5 | 15 | 3.5 | 1.79 | 1046 | 0.23 | 0.02 | 0.17 | 8.19 | 1.15 |
