No Friction Voice Coil Actuator 15mm Stator Voice Coil Motor No Tooth Groove
Voice Coil Motor No Friction Between The Rotor And Stator No Tooth Groove Effect Light Load
Voice Coil Motor No Friction Between The Rotor And Stator No Tooth Groove Effect Light Load
voice coil motor adopts the technology of direct drive without iron core, which has no friction between the mover and stator, no tooth groove effect, light load, extremely high response speed and excellent reliability.Suitable for high frequency short stroke motion system.It is widely used in medical treatment, semiconductor manufacturing, small precision replacement measuring instruments, active shock absorption system and vibration platforms.
| Performance rating | Unit | QY6-L20 |
| Total trip | mm | 15 |
| Peak thrust | N | 20 |
| Continuous thrust (under temperature Tmax) | N | 6 |
| Motor constant (under 25 ℃) | 4.3 | |
| Voltage | V | 24 |
| Peak current | Arms | 2.5 |
| Continuous current (under temperature Tmax) | Arms | 0.8 |
| The most powerful | W | 48 |
| Resistance(under 25°C±10%) | Ω | 9.65 |
| Inductance ±20% | mH | 3.3 |
| potential constant(under25°C±10%) | Vpeak/m/s | 7.5 |
| Thrust constant(under25°C±10%) | N/Arms | 7.5 |
| Rotor coil weight±15% | kg | 0.10 |
| Total weight±15% | kg | 0.77 |
| Maximum allowable coil temperature | °C | 150 |
| Positioning accuracy | um | ±5 |
| Repeat positioning accuracy | um | ±1 |
Voice Coil Motor outline dimension drawing
Voice Coil Motor application area
Voice Coil Motor test equipment
Voice Coil Motor certificate
FAQ
Q1. Can I have a sample order?
A: yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A: Sample needs 5-7 workdays.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: By express or air or sea .
Q5. How to proceed an order?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1 year warranty to our products.
Q8: How to deal with the faulty?
A: Our products are produced in strict quality control system and the defective rate will be less than 0.2%
Q9:How is your quality control?
A: Our professional QC will check the quality during production and carry out quality test before shipment.
